ADSS-48 double jacket
8 month ago
The ADSS cable boasts impressive characteristics. It's installable without power shutdown, delivering excellent AT performance with maximum inductive values reaching up to 25kV at operating point. Its lightweight and small diameter designs reduce ice and wind loads on towers and backprops. Span lengths can reach 500m or more, with good tensile strength and temperature performance. The design lifespan exceeds 30 years. Engineered with overhead power line conditions in mind, ADSS cable is designed for 110kV lines using PE outer sheath, while lines equal to or over 110kV employ AT outer sheath.
|
Ref. Outer Diameter |
Ref. Weight |
Ref.Max working tension | Ref. Allowable working tension | Break strength(KN) | Strength member CSA mm2 |
Modulus of Elasticity CSA (KN/mm2) |
Heat Expansion Coefficient |
| 12.5 | 125 | 1.5 | 4 | 10 | 4.6 | 7.6 | 1.8 |
| 13 | 132 | 2.25 | 6 | 15 | 7.6 | 8.3 | 1.5 |
| 13.3 | 137 | 3 | 8 | 20 | 10.35 | 9.45 | 1.3 |
| 13.6 | 145 | 3.6 | 10 | 24 | 13.8 | 10.8 | 1.2 |
We use various delivery methods depending on order size. For large orders, we ship by sea (LCL or FCL), while small orders can be shipped by sea (LCL), air, or courier services like DHL, UPS, and TNT. For reels, we offer 1000m, 2000m, and 3000m lengths, with options for custom packaging.
