GYTA33 SM Cable

8 month ago

21 0 

Guangzhou Jiqian Fiber Optic Cable Co.,ltd

9 month

Product details

GYTA33 Armoured fiber optic cable

Unitube's fiber optic cable features excellent mechanical and temperature performance. The steel wires armoring provides enhanced tensile strength, and submarine fiber optic cable ensures reliable transmission. AL tape longitudinal coverage acts as a moisture barrier, under sea fiber optic cable while the cable's cross-section is designed to block water or saltwater. The outer sheath protects the cable from ultraviolet radiation and optional flame retardance is available.

Item		Parameters
Loose tube	Material	PBT
	Color	Full-color spectrum
Filler	Material	PE
	Color	Black
CSM	Material	Phosphating steel wire
Armored	Material	Plastic-coated aluminum strip
Inner jacket	Material	PE
	Color	Black
Steel wire Armoured	Material	Galvanized steel wire
Outer jacket	Material	PE
	Color	Black
Min. bending radius	Static	12.5 times cable diameter
	Dynamic	25 times cable diameter
Tensile performance	Short term	10000N
Crush	Short term	5000N/100mm
Impact	Impact energy：1kg×1m; radius of hammer head:12.5mm; number of impacts: 5 No obvious additional attenuation, no fiber break, and no cable damage.

Unitube's fiber optic cable exhibits excellent mechanical and temperature performance. The armoring steel wires contribute to its significant tensile strength. AL tape provides longitudinal coverage as a moisture barrier, preventing water or saltwater ingress. The cable's cross-section is designed for water or saltwater blocking.

The outer sheath shields the cable from ultraviolet radiation and offers optional flame retardance. With a maximum installation depth of 250m underwater, this cable is suitable for various applications.
