Mining singlemode MGTSV fiber optic cable

Fire Resistance Armored Fiber Optical Cable, MGTSV, is a specialized communication optical cable designed specifically for the coal industry. It inherits the full performance of optical fiber cables and adds flame retardant and anti-rat properties, outdoor mining making it suitable for use in coal mines, gold mines, and iron mines. The cable's flame retardant characteristics ensure smooth communication in case of accidents, reducing losses and ensuring a safer working environment. With the certification of the State Administration of Work Safety, the MGTSV is approved for use in mines, tunnels, and roadways.

Item	48 cores MGTSV mining fiber optic cable
Attenuation Coefficient 1310nm dB/km	≤0.35
Attenuation Coefficient 1550nm dB/km	≤0.22
Number of loose tube (PBT)	4 loose tube, each tube contains 12 fibers
Central strength member	steel wire
inner sheath material	PE
outer sheath material	PVC or frame retardant
Tension (long term)	600N
Tension (short term)	1500N
Crush (long term )	600N
Crush (short term )	1000N

MGTSV fiber optic cable boasts excellent mechanical and temperature performance, with high-strength loose tubes featuring water-proof and high-strength properties. The special tube filling compound provides critical fiber protection, and good crush resistance and flexibility ensure reliable transmission.

For water tightness, the cable features a central steel wire strength member, 100% cable core filling, and PSP material for moisture-proof and anti-rodent performance. Additionally, blue flame retardant PVC as the second sheath enhances the cable's flame retardant performance.
