RCBO TNB1L-32G
4 year ago
MINI SAFETY BREAKER RCBO
NT50 type RCBO
Standard: IEC/EN 61009-1, GB 16917.1
Mini safety breaker
With 3 functions:
1. Earth leakage protection(Ground fault protection);
2. Over load protection;
3. Short circuit protection;
Advantage:
1.Compact size;
2.Easy assemblely;
3.Patent design;
|
TECHNICAL DATA: TNB1L-32G series RCBO |
||
| Product code | TNB1L-32G | |
| Protection | Over-load & Short circuit & Ground fault | |
| Rated current | 16A, 20A, 25A, 32A | |
| Characteristic | C curve(32A), D curve(16A, 20A, 25A) | |
| Rated residual current | Operating, IΔn | 15mA, 30mA |
| Non-operating, IΔno | 7.5mA, 15mA | |
| Poles | 2 poles | |
| Rated voltage | 110V AC, 220V AC | |
| Residual current off-time | 0.1s | |
| Standard | IEC/EN 61009-1, GB 16917.1 | |
| Approval | CE, CCC | |
| Type of trip | Short circuit | Electro-magnetic |
| Over load | Thermal / Bimetallic(2E) | |
| Ground fault | Electronic | |
| Breaking capacity | 2.5 KA | |
| Endurance | Electrical | 1000 operations |
| Mechanical | 2000 operations | |
| Material of body | Base | Bakelite |
| Cover in grey color | Plastic | |
| Cover in black color | Bakelite | |
| Type of operation | AC | |
| Length*Width*Height | 70mm * 32mm * 53mm | |
Exhibition:
