YZPST-BTA12-600SW TO-220A Table glass passivation process Voltage stability triac

3 year ago

92 0 

YANGZHOU POSITIONING TECH CO., LTD.

7 year

Product details

TRIAC

BTA12-600SW

TO-220A Table glass passivation process Voltage stability triac

●Product features

Single mesa structure (Single Mesa),

Table glass passivation process,

Voltage stability

The ability of strong current shock resistance

The applicable model： BTA12

●The main purpose

Washing machine, the hair straightened

Solid state relay, AC motor speed control

●Package

TO-220A

●Main Feature (Tj=25℃)

Symbol	Value	Unit
I_T(RMS)	12	A
V_DRM / V_RRM	600/800	V
VTM	1.55	V

●Absolute ratings (Limiting Values)

Symbol	Parameter	Value	Unit
I_TSM	Non repetitive surge peak on-state Current (tp=10ms)	115	A
I²t	(tp=10ms)	70	A²S
dI/dt	I_G=2I_GT，tr≤100ns,Tj=125℃	50	A/μs
IGM	Peak gate current(tp=20us)	4	A
PG(AV)	Average gate power	1	W
Tstg Tj	Storage temperature Operating junction temperature	-40--+150 -40--+125	℃

●Measure of package

TO-220A
