YZPST-K3002GRP Diode
6 month ago
| Rating | Symbols | K300 | Unit |
| Maximum repetitive peak reverse voltage （Sine Wsve,50to60Hz,TJ=-40to125℃) | VDRM VRRM | ||
| ±240 | V | ||
| On-state RMS current(TL=80℃,Lead Length=3/8",All Conduction Angles | IT(RMS) | ||
| ±1.0 | A | ||
| Peak Non Repetitive Surge Current | ±20 | ||
| (60Hz One Cycle Sine-wave,TJ=125℃) | ITSM | A | |
| Operating Junction Temperature Range | TJ | -40 to +125 | ℃ |
| Tstg | -40 to +125 | ℃ | |
| Storge Temperature Range | |||
| Thermal Resistance,Junction-to-led (LEAD LENGTH=3/8") | RθJA | 15 | ℃/W |
| Lead Solder Temperature | TL | 275 | ℃ |
| (Lead length≥1/16" from Case,10s Max) |
|
Characteristic |
Symbols |
YZPST-K3002GRP |
Unit |
|
Min |
|
270 |
|
|
Breakover Voltage,lBO=200μA |
VBO |
330 |
V |
|
Repetitive peak Off-State Current (50to60Hz Sine Wave) |
|
|
|
|
IDRM |
5 |
μA |
|
|
|
IBO |
|
|
|
Breakover Current |
200 |
μA |
|
|
Peak On_State Voltage |
|
Typ 1.5 Max 4 |
|
|
(ITM=1APeak,Pulse Width≤300µs,Duty Cycle≤2%) |
VTM |
V |
|
|
Dynamic Holding Current |
IH |
Typ 50 |
mA |
|
(Sine Wave,60Hz,RL=100Ω) |
Max 100 |
||
|
Switching Resistance (Sine Wave,50to60Hz) |
RS |
0.1 |
|
|
KΩ |
|||
|
Critical rate of rise of on_state Current, |
|
|
|
|
Critical Damped Eaveform Circuit (IPK=130Ω,Pulse Width=10μsec) |
di/dt |
120 |
|
|
|
|
|
A/μS |
