Poclain Ms08 Hydraulic Drive Pistoin Motor China OEM Manufacturer1

3 year ago

0 0 

Ningbo Hengnuo Hydraulic Drive Co.,Ltd

3 year

Product details

Basic Info.Ms05 Ms08 Ms25 Ms35 Ms50 Hydraulic Motor，hydraulic radial piston motor poclain MCR, high torque ,low speed ,poclain,
MS MCR SERIES RADIAL CAM-RING HYDRAULIC PISTON MOTORS ARE WIDELY APPLIED IN CONSTRUCTION,MINING MACHINERY, CEMENT EQUIPMENTS ,OCEAN ENGINEERING ,ENVIRONMENTAL PROTECTION,MILTARY INDUSTRY AND OTHER FIELDS,WHICH HAS THE CHARACTERISTICS : MODULAR DESIGN, THE ENTIRE STRUCTURE IS DESIGNED AS OUTPUT MODULE,FUNCTION MODULE,FLOW-DISTRIBUTION MODULE AND BRAKE MODULE, IT CAN COMBINE WITH AFFERENT MIAN MACHINES EASILY , WITH STAND STRONGER RADIAL AND AXIAL LOADS, THE OUTPUT MODULE OF PRODUCTS APPLIES BICONICAL ROLLER BEARING TO WITHSTAND STRONGER RADIAL AND AXIAL FORCES.
HIGHT EFFICIENCY AND STABLE AND IMPACT RESISTANCE WITH BRAKES .

Warranty

1 Year

Packaging

Standard Export Wooden Case.

Transport Package

Standard Export Wooden Case.

Specification

CE, SGS

Trademark

Origin

Ningbo, China

HS Code

8412291000

Production Capacity

500 Sets Per Month

Product Description

Poclain MS/MSE Series Hydraulic Motors:
MS02, MS05, MS08, MS18, MS35, MS50, MS83, MS125:
1). Radial piston type;
2). Adopt Imported Bearing and Oil Seal, etc.
3). Modular design, High efficiency, High pressure and smooth running even at very low speeds.
4). Permissible Radial and Axial load, Motor with multi-disc brake, Motor emission control.

Ms/Mse Series Ms05 Ms08 Ms25 Ms35 Ms50 Hydraulic Motor

Ms/Mse Series Ms05 Ms08 Ms25 Ms35 Ms50 Hydraulic Motor

Model	displacement (ml/rpm)		rated pressure (MPa)	maximum pressure (MPa)	rated pitch of strand(N. m) (whole displacement)	speed range (rpm)	maximum power(kw) (whole displacement)
Model	whole displacement	semi-displacement	rated pressure (MPa)	maximum pressure (MPa)	rated pitch of strand(N. m) (whole displacement)	speed range (rpm)	maximum power(kw) (whole displacement)
MS02	213		25	40	796	0-310	16
MS05	468	234	25	40	1749	0-200	25
MS08	780	390	25	40	2914	0-170	36
MS11	1048	524	25	40	3916	0-160	44
MS18	1747	873	25	40	6528	0-150	62
MS25	2498	1249	25	40	9334	0-130	80
MS35	3494	1747	25	40	13055	0-100	97
MS50	4996	2498	25	40	18667	0-100	123
MS83	8328	4164	25	40	31098	0-80	176
MS125	12500	6250	25	40	19875	0-50	240
