High temperature resistance ceramic pall ring random packing 1inch 2inch 3inch for water treatment1
3 year ago
High temperature resistance ceramic pall ring random packing
Introduction
| Model: | Pall Ring | |||||
| Shape: | Ring | |||||
| Color: | Light Grey | |||||
| Chemical composition | ||||||
| SiO2 | Al2O3 | Fe2O3 | CaO | K2O+Na2O | ||
| >70% | 23-30% | <1% | <1-2% | <2-4% | ||
| Technical data | ||||||
| Diameter (mm) | D*H*T(mm) |
Surface area (m2/m3) |
Free volume (%) | Number per m3 | Bulk density (Kg/m3) | Dry Packing Factor (m-1) |
| 38 | 38*38*4 | 150 | 75 | 13400 | 570 | 356 |
| 50 | 50*50*5 | 120 | 78 | 6800 | 550 | 252 |
| 80 | 80*80*8 | 75 | 80 | 1950 | 520 | 146 |
| Physical properties | ||||||
| Index | Value | |||||
| Specific gravity(g/cm3) | 2.25-2.35 | |||||
| Water absorption (%) | <0.5 | |||||
| Acid-resisting strength, %Wt. Loss (ASTMc279) | <4 | |||||
| Firing temperature(Degree C) | 1280-1320 | |||||
| Softening point( Degree C) | >1400 | |||||
| Density(kg/m3) | 2350 | |||||
