Metal Random Tower Packing 25mm 38mm Stainless Steel SS304 SS316 Conjugate Ring1
3 year ago
Metal Random Tower Packing 25mm 38mm Stainless Steel SS304 SS316 Conjugate Ring
Technical Parameter:
| Size | Number | Weight | Surface area | Free volume |
| per m3 | (kg/m3) | (m2/m3) | (%) | |
| No.0.7 | 167400 | 177 | 226 | 97.7 |
| No.1.0 | 67100 | 179 | 168 | 97.7 |
| No.1.5 | 26800 | 181 | 124 | 97.6 |
| No.1.75 | 20200 | 155 | 106 | 98 |
| No.2.0 | 13600 | 144 | 96 | 98.2 |
| No.2.5 | 8800 | 121 | 83 | 98.4 |
| No.3.0 | 4200 | 133 | 66 | 98.2 |
Advantage
Improved efficiency due to lateral liquid diffusion and surface film renewal
Outstanding surface utilization in mass and heat transfer applications
Shorter packed bed heights
Maximum piece-to-piece contact with minimal nesting
High strength to weight ratio allows up to a 15 metre bed height
Consistent performance due to uniform randomness
Free flowing particle design facilitates installation and removal via uniform randomising.
