High Hardness And Corrosion Resistance Alumina Ceramic Tube
Reputation depends on quality, quality comes from Hard!
Alumina Ceramic:
Alumina ceramic dry press forming technology is limited to articles with a simple shape and an inner wall thickness of more than 1 mm and a length to diameter ratio of not more than 4:1. The forming method is uniaxial or bidirectional. The press is available in hydraulic or mechanical form and can be semi-automatic or fully automatic. The maximum pressure of the press is 200Mpa. The output can reach 15 to 50 pieces per minute. Since the hydraulic press has a uniform stroke pressure, the height of the pressed parts is different when there is a difference in the filling of the powder.
properties:High hardness, high strength, wear resistance, corrosion resistance, high temperacture (1600°), good thermal diffusivity, good insulativity, low cost etc.
Data Sheet↓
Color: White/IvoryDensity: 3.9g/cm3
Alumina Content: 96% 99% 99.5%
Gas permeability: 0
Water Absorption: 0
MONS' Hardness: 82
Vickers Hardness (Hv50): 15.7(1600) Gpa(Kg/mm²)
Flexural Strength(20°C): 330Mpa
Compressive Strength(20°C): 2000Mpa
Fracture Toughness (20°C): 4 MPam1/2
Thermal Conductivity(20°C): 27.5W(m.K)
Thermal Expansion Coefficient: 7.6 10-6/°C
Thermal Shock Resistance: 200 △T°C
Maximum use temperature 1650°C
Dielectric Strength: ＞10 KV/mm
Dielectric Constant: 9.1er
Dielectric Loss Angle(1MHz): 0.0002-0.0003
Volume Resistivity(20°C): ＞1014Ω.cm
Specific application: Electrical ceramic substrate, plunger, sealing ring etc.
Company Information:
Shenzhen Hard Precision Ceramic CO.,Ltd founded in 2007, located in Shenzhen of China. We are a company that integrates development, design, molding, sintering, production and sales of precision ceramic products. After 10 years of development, we have cooperated with more than 2000 customers and 60 universities; Our factory covers an area of 2000 square meters, 50 employees, and annual production value of nearly 20 million. We have a higher visibility and better reputation in the same industry.Our products include ceramic rods, tubes, plates, blocks and precision parts for industrial. We have all-line high precision equipments from ceramic forming, sintering to precision machining. Hope for a wide range of sincere cooperation with customers at home and abroad.
1.12 years of professional production industrial ceramics factory
2.High quality products with low price
3.High precision parts with lowest tolerance
4.Show time for production
5.Has a group of experienced, professional and efficient R&D team
6.Has a good reputation in China and abroad.
7.MOQ is not limited, small quantity is welcome.
8.Vigorous team and good after-sales service
Products Show
Factory Show
Our Team
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-30 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
