Ertalyte®Pet Ertalyte Cnc Part is an unreinforced, semi-crystalline thermoplastic polyester based on polyethylene terephthalate (PET-P). It is manufactured from proprietary resin grades made by Quadrant. It is characterized as having the best dimensional stability coupled with excellent wear resistance, a low coefficient of friction, high strength, and resistance to moderately acidic solutions. Ertalyte®'s properties make it especially suitable for the manufacture of precision mechanical parts which are capable of sustaining high loads and enduring wear conditions. Ertalyte®'s continuous service temperature is 210F (100C) and its melting point is almost 150F higher than acetals. It retains significantly more of its original strength up to 180F (85C) than nylon or acetal.

In addition, Ertalyte®PET-P offers good chemical and abrasion resistance. Its low moisture absorption enables mechanical and electrical properties to remain virtually unaffected by moisture. Ertalyte® PET-P can be machined to precise detail on standard metal working equipment.

Ertalyte® is FDA compliant in natural and black. Natural Ertalyte® is also USDA, 3A-Dairy and Canada AG compliant.

Ertalyte® TX is an internally lubricated thermoplastic polyester providing enhanced wear and inertness over general purpose

nylon(PA) and acetal(POM) products. Containing uniformly dispersed solid lubricant, Ertalyte® TX provides a lower wear rate and coefficient of friction than unmodified polyesters like PET or PBT and even internally lubricated materials like Delrin® AF blend.

Ertalyte® TX excels under both high pressure and velocity conditions. It is also ideally suited for applications involving soft metal and plastic mating surfaces.

Black Ertalyte Component is a milky white or light yellow highly crystalline polymer with a smooth and shiny surface. It is resistant to creep, fatigue, abrasion and dimensional stability, low wear and high hardness, and has the highest toughness in thermoplastics: good electrical insulation, low temperature, but poor corona resistance. Non-toxic, weather-resistant, chemical-resistant, good water absorption, low acid resistance and organic solvents, but not soaked in heat-resistant water, not resistant to alkali.
