high performance door
3 year ago
PVC high speed rolling shutter door can be designed according to the needs of customers. These high speed roller shutter doors can be used in clean room , firms, inside or outside. The fact that it is not used on a fixed area provides a flexible usage possibility. According to the needs of the firms, they can easily choose PVC rolling doors in the building areas. In addition, it can be used in exterior areas and provides a wide usage area. Fast PVC rolling door can be produced by coating fabric. The different colors of the fabric can be helpful in separating parts of the business. The function of the tarps is not only aesthetic, but also contributes to the protection of the door system against impacts. Since the impacts of the fabric do not come into direct contact with the door surface, it is inevitable that the door will be protected and long-lasting. The fabric can be a very important material so that the door receives as little damage as possible from impacts. Of course the fabric is resistant to a certain level of impact and there is also the possibility of damaging the fabric. You can contact our company for repair of PVC Fabric Roll Up Door. Standard: 0.7 m/s It can be increased up to Maximum opening: 1.5 m/s Maximum closing: 0.4 m/s Aluminum wind rail: 35km/h Brands: Mehlar, Heytex, Sioline Thickness of normal fabric: 1 mm Thickness of transparent fabric: 2mm Manually Operated Optional: It can be operated with UPS in case of power eut Sides struts, lower parts, wind rails, and drums are aluminum. Sides of the upper parts are coated with galvanize.
Hongfa fast shutter doors by the Division we learn from foreign advanced technology and equipment , and to draw on the advantages of similar products in domestic self-developed high-tech products , with insulation , insects, wind , dust, noise, anti-odor, lighting and many other features , the high speed door can be widely used in food , chemical , textile , refrigeration , electronics , printing , assembly , precision machinery , logistics . warehousing and other places , the high speed rolling shutter door Can be extremely satisfying frequent high-performance logistics and clean place with a variety of needs and saving energy , increasing air-conditioning effect , fast closing , improve operational efficiency and create a better work environment
1. Frame: 2MM thicknesses cold-roll Stainless steel or aluminium alloy .
2. Motor : Germany SEW brake motor .
3. Control system: Imported Japan Mitsubishi converter and PLC to control of electric box
4. Opening & closing speed: 0.6-1.5m/s (adjustable).
5. Safety Device: Korea Photocell Sensor, emergency stopping reaction when sensing obstacles.
6. Curtain: France high-density polyester fiber and the surface coating processing, thickness 0.8-1.5MM, variety colors can be chose: Red, yellow, blue, green, orange, gray, white, transparent, etc. Usage temperature: -30 ° C +70 ° C .
7. Wind resistant: The Aluminium alloy Reinforce Girder to increase wind resistant effect.
8. Curtain replacement function: Aluminium alloy Reinforce Girder is loaded between 2 pieces Curtain, can be replaced easily if any curtain broken , save your cost.
9.Transparent window: 1.2MM thickness transparent PVC window, size and location is Customized
10. Seal: Seal brush are Installed inside the guides, and the special bottom design .
11. Cotrolling way: Push button + radar sensor, very convenient.
12. Limiting Switch: Mechanical limiting switch, easily and exactly.
13. Emergency STOP : With emergency stop button on control panel, can stop easily by
Hand once disconnect or accident
14 All Hongfa's production is with fault recovery function, system will self-recovery after power cut off.
15. Delivery time: About 7 business days with contract and deposit confirmed.
16. Pyament item: 50% before production, and the other 50% before shipment.
17. Warranty Details: We provide 12 months warranty for all doors and accessories
