Raschel Net Warp Knitting Machine
Main Introduction:
Raschel net machine applied at netting fields with different kinds of yarn.
The high-performance compound needle raschel net machine has developed for many kinds of net fabrics, e.g., knotless fishing net, protective net, bale net, sports net, packing sack, sunshade net etc. The wider width up to 12m make the production extremely high.
Crankshaft system, EBC let-off device with electric take-up and batching device, EL control system makes pattern changing very convenient and efficient.
We make raschel net machine from 4bar to 8bar with wide width range from 134 inch to 460 inch. The concept of our raschel net machine is based on easy operation and high efficiency. Touch screen interface can record all the production data and fabric parameter which can be transferred via internet for better production management.
Technical Specifications:
FABRIC SPECIFICATIONS
Working
Width
42" ~ 470"
Gauge
E2 ~ E22
Bar
2,4,6,8 bars
BARS/KNITTING
ELEMENTS
Individual
needle bar
magnesium bar
standard
Knock over comb bar
magnesium bar
standard
Sinker
bar
magnesium bar
standard
Ground
bar
magnesium bar
standard
WARP
BEAM SUPPORT
Free
standing
application
30''/40"/50" beams
MACHINE
DRIVE AND CONTROL
Main
motor
invertor regulated
control
standard
WARP
LET-OFF DEVICE
EBC
electric control
standard
CLOTH
TAKE-UP DEVICE
EAC
electric control
standard
BATCHING
DEVICE
Electric
friction driven
standard
Batching
diameter
PATTERN
DRIVE
Pattern
disc
standard
EL
via electric motor
optional
MONITORING
& SOFTWARE
HMI
monitoring and reporting
via display
standard
Cotex
Suite
optional
OIL
SUPPLY
Heater
exchanger
heating and cooling
optional
SAFETY
Light
curtain
depending on country of
delivery
optional
