Plain objects conveyor screen printing machine

Machine introduction of Plain stencil screen printing machine with conveyor belt

      Conveyor Belt Flat screen Printing Line is a production line equipment that integrates conveyor belt technology and flat stencil printing technology. It can continuously transport items to the printing station for precise printing through the continuous movement of the conveyor belt, realizing continuous, efficient and high-quality printing operations. It is widely used in packaging, advertising, printing and publishing and other industries that require continuous and large-scale printing. At the same time, regular cleaning, inspection, lubrication, tension adjustment and operator training and other maintenance and maintenance work are required to ensure the stability and reliability of the equipment, improve production efficiency and extend service life.

       The flat screen printing equipment with a fixed worktable has discontinuity in product transmission. In the process of printing a product, there is a considerable amount of intermittent time wasted. The screen printing equipment installed with a conveyor belt makes up for this defect very well. The belt keeps moving continuously, the operator puts the product on the designated position of the conveyor belt and performs necessary positioning, then enters the printing position for printing, and then the conveyor belt continues to run, which can ensure continuous printing of the product.
   The screen printing equipment  for the conveyor belt is very suitable for products with uniform shape but simple positioning, such as cut pieces of clothes, plastic decorative panels, paper cards, metal panels, and mouse pads. The screen printing equipment on the conveyor belt is also easier to connect with the front-end assembly line or the rear-end IR tunnel furnace and UV curing machine to achieve integrated printing.
The conveyor belt can be adjusted steplessly, and the stop position can be set and a simple positioning device can be installed to ensure the consistency of printed products and the accuracy of printing quality.

     The conveyor belt screen printer uses a continuously running conveyor belt to replace the traditional fixed workbench screen printer. The product is placed on the conveyor belt, which can run continuously and stop during printing. After printing, it continues to run according to the set conveying interval to print the next product. The conveyor belt screen printer saves the time of picking up and placing products, so the efficiency is improved to a certain extent.

In addition to the characteristics of a screen printer, the conveyor belt screen printer also has the following advantages:

Wide range of printing

• Diverse substrates: As long as it is a sheet, regardless of the material, plastic, rubber, leather, cloth, etc., the conveyor belt screen printer can be used;

• Flexible size: The screen frame size can be customized according to needs, and can print large-format patterns and texts, and can achieve large-area printing. It can also print small-size fine patterns by adjusting the printing area size.

Easy operation and maintenance

• Convenient operation: Usually PLC touch screen control is adopted, the operation interface is intuitive, simple, and easy to use. Workers can operate proficiently after short-term training, which reduces the professional skills requirements for operators. The constant pressure device of the screen printer scraper can ensure that the printing pressure is uniform and stable, and the parameters such as pressure size and printing position can be adjusted, which can adapt to products of different heights and different printing patterns and requirements.

• Low maintenance cost: The structure is relatively simple, and the parts are easy to replace and repair. Daily maintenance mainly involves cleaning and replacing the screen plate, adjusting the scraper plate, etc., and the maintenance cost is low.

High production efficiency

• Automatic transmission: The conveyor belt is used for intermittent automatic transmission printing, which can realize continuous automatic printing, greatly improve production efficiency, reduce labor costs, and is suitable for large-scale production.

• Adjustable speed: The printing speed can be adjusted according to actual production needs. Under the premise of ensuring printing quality, the production speed can be increased to meet the production requirements of different order quantities.

Application-printed samples

• Packaging industry: used for printing of various packaging materials, such as cartons, plastic bags, labels, etc.
• Advertising industry: used for printing and production of billboards, such as outdoor advertising, promotional posters, etc.
• Electronic industry: used for printing of electronic product shells, labels, etc.
• Automotive industry: used for printing of labels, logos, etc. for automotive parts.

Technical Data

Advantages of Stencil screen printing machine with conveyor

• Reduced costs: Automated production reduces labor costs and improves production efficiency, thereby reducing overall costs.
• Improved precision: Accurate control systems and stable printing processes can ensure improved printing precision and meet high-quality printing needs.
• Easy to manage: Automated production lines are easy to manage and monitor, and the control system can be used to understand the production status in real time and make adjustments.
• Environmental protection and energy saving: Compared with traditional printing methods, conveyor belt flat printing lines are more environmentally friendly and energy-saving in terms of energy consumption and waste emissions.
