Features:
l Applications: Suitable for extruding all types of polyene materials
l Suitable screws: 25,30,45, 65, 75,90, 120, 150,
l Controller: Normal, PID or PLC (optional)
l Can be combined with various auxiliary machinery
l Length / diameter ratio can be changed (suitable between 25: 1 - 38: 1)
l Lower specific energy consumption; energy saving could be up to 30% plus.
l Higher capacity: the capacity could be 50% more at the same diameter
l Higher efficiency in plastication.
l Better mixing effect: it is comparable with normal twin screw extruder
l More accuracy in extrusion processing control.
|
Model |
Screw diameter (mm) |
L/D ratio |
Main motor power (KW) |
Capacity (kg/h) |
|
SJ-25 |
45 |
25/1 |
2.2 |
5 |
|
SJ-30 |
30 |
25/1 |
5.5 |
10 |
|
SJ-45 |
45 |
25-33/1 |
7.3-37 |
50-150 |
|
SJ-65 |
65 |
25-33/1 |
22-90 |
60-250 |
|
SJ-75 |
75 |
25-33/1 |
55-110 |
200-350 |
|
SJ-90 |
90 |
25-33/1 |
37-185 |
180-550 |
|
SJ-120 |
120 |
25-33/1 |
75-280 |
320-800 |
|
SJ-150 |
150 |
25-33/1 |
90-355 |
400-1200 |
