Poster large format screen printer with vacuum table
Usage
- It is a flat screen printer with a suction function and is suitable for printing in thin products such as paper, PVC film, plastic film, textile, etc., which are easy to walk in the printing process. Printing the largest area: 600 * 800 mm;
- Structural design using screen up and down sports, more conducive to product removal and placement;
- Stable horizontal cylinder design, blowing ink pressure uniform, back to the ink formation, printing quality is good;
- Can be semi-automatic operation, the user interface is good;
- Machine debugging process set up a single function operation, set up to complete the full operation;
- Widely used in paper packaging, mirror printing, glass printing, machine panels, stickers printing, combined with a variety of processes, can achieve UV scrub, UV onions, UV local varnish and coating process. Also widely used in water mark transfer paper, thermal transfer paper printing.
- Screen printing machine and the screen plate are used up and down the use of high-precision hardened guide shaft structure, high parallelism, operating error can be controlled within 0.05mm, is a high-precision flat screen printing machine commonly used in the form of institutions;
- Widely used in high-precision screen printing tasks such as: circuit boards, dot printing, membrane switch, ink layer thickness requirements of the printing area.
Technical Parameters
| Item | PS-100180PVH | PS-120240PVH | ||
| Printing height(mm) | 0-20 | 0-20 | ||
| Air(liter/min) | 55 | 60 | ||
| Worktable dimension(mm) | 1400×2300 | 1600×2600 | ||
| Max. frame size(mm) | 1600×2600 | 1800×3000 | ||
| Max. printing area(mm) | 1000×1800 | 1200×2400 | ||
| Max. printing speed(pcs/h) | 400 | 300 | ||
| Max Stroke of up-and-down frame(mm) | 200 | 200 | ||
| Max stroke of Squeegee(mm) | 1800 | 2400 | ||
| Squeegee motor wattage(w) | 500 | 500 | ||
| Table Precision(mm) | +-0.13 | +-0.13 | ||
| Package dimension(mm) | 2.51×1.26×1.63 | 3.35×1.96×1.63 | ||
| G.W.(kg) | 541 | 570 | ||
| Works supply |
380 V-220 V Power supply; 5-7 Bar compress air |
|||
Machine advantage
- The four-column structure, the platform inside and outside of the platform, the web version vertically up and down, the printing head left and right.
- The platform, the web version and the printing process adopt the independent drive source, the motion coordination, the speed is stable adjustable.
- PLC control system and man-machine interface.
- High strength alloy drawing aluminum printing girder.
- Variable frequency motor drives the printing tool holder, photoelectric eye control stroke, independent adjustment, intelligent quantitative control speed.
- The printing driven guide adopts the precision orientation of the straight square guide rail.
- Fluctuation motor drive screen and printing girder up and down, smooth movement.
- In Taiwan, the line guide rail of silver 50 is synchronized to the same direction.
- The overall fine grinding stainless steel platform runs in a straight line to the printing position and the upper material.
- The printing platform is operated by Taiwan intelligent numerical control reduction motor drive, linear square guide rail precision orientation, photoelectric eye precise control positioning.
- The upper material is on the outer end and runs to the other end for the printed area namely the inner end.
- The printing platform with fan, can choose long time adsorption and automatic suction mode.
- Printing platform level and vertical direction with precision fine tuning handle, fine tuning precision, color matching for easy edition.
- The operation interface has a variety of humanized printing modes, automatic printing indirect time digital control (1~9 seconds).
- The independent design of the head lifting device, scraper/return ink knife, net edition loading and unloading and screen cleaning are convenient.
- The control device of the right and left net clamping arm is easy to adjust. Pneumatic interlocking fixed screen device.
- The Angle of the scratch and the return ink can be adjusted, and the pneumatic automatic synchronizing off the net device.
- Printing scraper with anti-drop ink system to ensure more uniform printing color.
