Fully automatic image measuring instrument

  The full-automatic video image measuring instrument uses CCD digital images and computer screen measurement technology with powerful software capabilities of spatial geometry operation. The instrument's brain and software soul are installed in a computer with exceptional control and graphic measurement software. It can read the displacement value of the optical ruler quickly and obtain the desired result through software module operation based on space geometry.
  The graphics generated on the screen allow the operator to compare images, and any deviation of measurement results can be visually distinguished. All of these operations are done in real-time, with the help of the powerful computing power of the computer, which the operator cannot detect. This precision instrument can use CCD digital images through computer software operation to meet the needs of complex measurement. The fully automatic image-measuring instrument is an advanced stage of image measurement technology with remarkable software and hardware performance, making coordinate size measurement convenient and comfortable. It has a self-learning function based on machine vision and process control. It can learn and memorize the measurement process's path, focusing, point selection, function switching, manual correction, light matching, and other operating methods, relying on the high-speed and accurate micrometer-level displacement of digital instruments.
  The full-automatic image measuring instrument can quickly learn all of the operator's practical operation processes to achieve artificial intelligence. By combining its automatic focusing, area search, target locking, edge extraction, and fuzzy operation of rational matching points, it can automatically correct the deviation caused by workpiece and displacement differences, achieving accurate point selection with high precision repeatability. This frees the operators from monotonous operations, such as accurate visual alignment, frequent point selection, repeated displacement, function switch
