Metal Push Button

19mm High Life Waterproof Metal Push Button Switches

YC19 Series Anti Vandal Switches feature a long life expectancy, the Momentary Push Button Switch could reach 1,000,000 cycles and self lock Push Button Switches is 500,000 cycles. We have multiple actuator options could be choose and the actuator is normally made of stainless steel, nickel plated or aluminum alloy. The contact rating of our 19MM Metal Switches is 5A 250VAC, which could support bigger equipment.

The 19mm Metal Push Button Illumination LED colors include red, yellow, orange, blue, green, white, bi-colors and LED options, for an almost unlimited choice of illumination colors. Available in dot or ring illumination with graphics options that include the power symbol etched or illuminated.

SPECIFICATIONS:

RATING: Ith 5A/250VDC resistive load 5A/250VAC

CONTACT RESISTANCE: 50 mΩmax. @1A 12 VDC

INSULATION RESISTANCE: 1,000 mΩmax. @500VDC

DIELECTRIC STRENGTH: 2,000V RMS@sea level

OPERETION TEMPERATURE: -20°to 55°

MECHANICAL LIFE: Momentary 1,000,000 cycles

                                     Self-lock 500,000cycles

ELECTRICAL LIFE: 50,000 make-and-break cycles at full load

PANEL THICKNESS: 10MM(∅19.2mm)

INGRESS PROTECTION: IP65,IK10(Stainless)

Our Advantages

From the purchase of raw materials to the finished product, all production process (product development/plating/mold and equipment processing/ metalpressing/ plasticinjection/semi-automatic and fully automated equipment assembly, etc.) are completed in the factory. Our metal pressing and plastic injection own the advantages of 100% self-made mold, from a single form to the various forms of application. And we continuously keep innovation and enhance the technology in order to collaborate with our customers to design the most sophisticated products. Yeswitch Electronics Co., Ltd., whether in production base or in quality assurance department in the head office, have professional equipment and technical personnel. In addition to the annual new product development, product improvement and testing are performed as annual plan to ensure that listed products maintain in best quality. Therefore, our long-term customers/partners, get the best quality of the switches.
