Cumulative Weighing Batching Plant
The PLD800-4800 Aggregate Batching Plants is applicable in different situation, such as bridges and road construction and residential , commercial, industrial constructions .
|
Model |
PLD800 |
PLD1200 |
PLD1600 |
|
Volume of weighing hopper |
800L |
1200L |
1600L |
|
Storage bin capacity |
2m3×3 |
2.4m3×3 |
15m3×4 |
|
Productivity |
48m3/h(drier) |
60m3/h(drier) |
80m3/h(drier) |
|
Batching accuracy |
±1% |
±1% |
±1% |
|
Maximum weighing magnitude |
1500kg |
3000kg |
3000kg |
|
Kinds of batching aggregate |
2 |
2–3 |
3–4 |
|
Feeding height |
2400mm |
3000mm |
3000mm |
Attentions:
1 If the control system can’t work normally accidentally, you can turn it off and restart.
2The first batching and weighing process is a procedure of automatic drop reversion, and it will batch materials depending on this rectification result later on.
3 Pay attention to the weighing hopper which may be stuck by something.
4 Check the circuit and see whether there is something wrong before starting, and remember not to place sundries in the case.
concrete batching machine in concrete batching plant
