CL-65/90/65A 1500mm PE Co-extrusion Plastic Wrapping Film Unit

Product Description of CL-65/90/65A 1500mm PE Co-extrusion Plastic Wrapping Film Unit

1.Thickness Adjustable Scope for PE  Plastic Wrapping Film Making Line :10µm-50µm;

2.Screw Diameter : A:65mm

                              B:90mm

                              C:65mm

3.Width of Effective Film of PE Plastic Wrapping Film Making Unit :1 500mm(max) or 3*500mm ;

4.Structure of Film Layers of PE Plastic Wrapping Film Making Plant :A/B/C or A/C/B/C/A Co-extruded;

5.Raw Material of Plastic PE Wrapping Film Making Line:LLDPE;

6.Extrusion Capacity(Max) of PE Plastic Wrapping Film Making Unit:250kg/h.

7.Linear Speed of PE Plastic Wrapping Film Making Plant : 135m/min

8.Installation Dimension(L*W*H) of PE Plastic Wrapping Film Making Line:9.6*4.5m*4.5m

9.Weight of PE Plastic Wrapping Film Making Unit:14T

Features of CL-65/90/65A 1500mm PE Co-extrusion Plastic Wrapping Film Unit

1. The alloy screws are processed with special mixing refining and are desgned for high plasticity.This PE Plastic Wrapping Film Making Line is consisted of imported static state mixer to ensure good plasticity and high quality output.

2. The winding system of this PE Plastic Wrapping Film Making Unit is equipped with online air knife device which can automatic cut the main roller of film into different width film roller.

Packing of the CL-65/90/65A 1500mm PE Co-extrusion Plastic Wrapping Film Unit

The seller provides the simple pearl wool with film package & wooden motherboard for the CL-65/90/65A LLDPE Plastic Wrapping Film Making Unit.

Certificate of CL-65/90/65A 1500mm PE Co-extrusion Plastic Wrapping Film Unit

Service Team of CL-65/90/65A 1500mm PE Co-extrusion Plastic Wrapping Film Unit

Warranty period and testing procedure:

The seller freely provides the fittings during the warranty for 12 months with the maintenance forever

when the equipment is tested OK. (Human factor and force irresistant factor exception.)

The seller provides the debugging and setting, Seller free to provide about one week training

and the buyer should provide the round-trip ticket and other traveling costs.

Warmly Welcome To Visit Our Factory
