PS Control Conbinet

“PS” PUSH-BUTTON PANELS AND “DS” JUNCTION BOXES
• EN 1.4301 (TYPE 304L) s/s execution, thickness 12/10, fine satin-finish. Available on demand in other types of s/s, as well as customized.
• Cutting-edge welding procedures enable to maintain unaltered the chemical formulation of the material thus avoiding corrosion in the weld areas.
• The cover is secured by special “leak-proof” M5 screws.
• Gasket made of closed-cell foamed neoprene rubber, oil-proof and self-extinguishing.
• Protection degree IP66, when appropriate components are properly installed, as per CEI EN 60529 rules.
• Pre-arrangement for earthing in compliance with the applicable rules. For the push-button panel, a special collar of tinned brass is supplied for positioning under a block, in direct contact with the sheet.
• On the bottom are applied  S/S M6 stud bolts to secure structural steel and bars.
• The PS series has a drilled cover to accommodate the Ø 22,5 standardized push-button panel.
• Inner plate in sendzimir  execution (on request).
• The enclosures of the series PS-DS can be pressurized according to CEI 64-2 and CEI 31-1 for A-SI security systems and enclosures featuring Ex-p inside overpressure.

Our company's main products include AE Control Cabinet、AK Control Cabinet、Computer Cabinet、Operation Control Desk、Computer Cabinet.
