Batching Machinery PLD4800
The concrete batching machine consists of feeding system, weighing system and electric control system. The feeding system arranges in a line and feeds with a loading machine. And the weighing system can weigh precisely with a sensor.
|
Model |
PLD4800 |
|
Volume of weighing hopper |
4800L |
|
Storage bin capacity |
30m3×4 |
|
Productivity |
280m3/h(drier) |
|
Batching accuracy |
±1% |
|
Maximum weighing magnitude |
6000kg |
|
Kinds of batching aggregate |
3–4 |
|
Feeding height |
3600mm |
|
Transition belt speed |
1.6m/s |
|
Power |
22kw |
|
Weigh |
10200kg |
|
Size (l×w×h)(mm)
|
15520×3900×5090 |
concrete mixer ,concrete batching machines in concrete batching plant
Advantages
▪ The machine adopts detachable structure, which makes it easy to be fed
▪ It can batch several kinds of materials automatically according to the mixture ratio set by users
▪ Electric weighing with a sensor has advantages of accurate weighing and precise batching. And with strong microcomputer control system, users can operate it just with a key
▪ A cover at the top of belt machine can prevent spilling effectively
▪ Easy to clean, maintain and service
