                                                          WBZ400 Stabilized Soil Mixing Plant

Stabilized soil is necessary for constructing buildings and other structures, as it provides a solid base for the foundation to rest on.It is necessary for building roads, bridges, and other infrastructure, as it provides a stabilized base for these structures.

A stabilized soil batching plant,which includes stabilized soil batching machine,stabilized soil mixer , cement silo,and screw conveyor,ensures consistent quality of soil mixtures. This is because the plant is designed to accurately measure and mix the right proportions of soil, cement, and water, ensuring that the end product meets the required specifications.

XinFeng Machinery products high quality stabilized soil mixing plant,which can product 400t stabilized soil per hour.

Besides,You can also order the truck scale to accurately weigh the soil’s weight in the truck.

Parameters of WBZ400 Stabilized Soil Mixing Station：

	WBZ 400 stabilized soil Batching Plant
Global Parameters	Rated production capacity		400t/h
	Total power		≈100KW
	Maximum aggregate diameter		60mm
	Aggregate weighing accuracy		≤±1%
	Powder weighing accuracy		≤±1%
	Occupied area		45×10=450㎡
Mixer	Structure		Double horizontal shaft forced continuous type
	Capacity		0-400t/h
	Amount of blades		40
	Material of blades		chromium molybdenum alloy
	Maximum material diameter		60mm
	Motor power		55KW
	Model of reduction machine		ZQ650
Aggregate Batching System	Hopper (quantity)	Volume	6m³（Twin hopper）
		Height	3420m
		Hopper amount	4
	Calculate system	Weighing computer belt	4
		System accuracy	≤±1%
		Calculate speed	≤400t/h
		Belt width	650mm
