Product Description
Axial magnetic field motor is also known as disk permanent magnet motor, axial magnetic field motor’s air gap is planar, The air gap magnetic field along the axial distribution, the motor stator structure is easy to Make core and winding cooling,it can get more heat dissipation area; because of its compact structure (axial size is short), small size, high efficiency, high power density, Good speed control performance. small moment of inertia, high reliability and short magnet circuit and it attracted more and more attention. They are widely used in new energy electric car, renewable energy systems, industrial equipment which require high torque density and compact occasions.
| Rated voltage | 48V |
| Rated power | 400W |
| Rated current | 104A |
| Rated speed | 1500rpm |
| Rated torque |
25.5N.m |
| Peak torque |
75N.m |
| Motor shaft diameter | 28mm |
| Motor length | 133mm |
| Flange | 100B5 |
| Encoder | if you need encoder, kindly advise |
| Brake | if you need brake, kindly advise |
|
Weight |
17kg |
|
Motor Power cable |
MA /U |
MB /V |
MC /W |
|||
|
Yello |
Green |
Blue |
||||
| Hall cable | 5V | GND | HALL A | HALL B | HALL C | |
| Red | Black | Yellow | Green | Blue | ||
| Brake cable |
If you need brake, kindly advise. |
|||||
48V 4KW BLDC MOTOR 1500RPM
| Model | Voltage | Power | Rated speed | Rated current | Rated torque | Peak torque | Length | Shaft Dia | Weight | |
| Frame | Unit | V | W | RPM | A | N.m | N.m | mm | mm | kg |
| 60*60mm | KY60AS0201-30 | 24 | 100 | 3000 | 5.4 | 0.31 | 0.95 | 147 | ⌀11 | 1.4 |
| KY60AS0202-30 | 24 | 200 | 3000 | 10.4 | 0.63 | 1.89 | 147 | ⌀11 | 1.4 | |
| 80*80mm | KY80AS0202-15 | 24 | 200 | 1500 | 10.4 | 1.27 | 3.8 | 142.5 | ⌀14 | 2.3 |
| KY80AS0402-15 | 48 | 200 | 1500 | 5.2 | 1.27 | 3.8 | 142.5 | ⌀14 | 2.3 | |
| KY80AS0204-15 | 24 | 400 | 1500 | 21.3 | 2.55 | 7.65 | 185 | ⌀14 | 3.5 | |
| KY80AS0404-15 | 48 | 400 | 1500 | 10.4 | 2.55 | 7.65 | 185 | ⌀14 | 3.5 | |
| KY80AS0204-30 | 24 | 400 | 3000 | 21 | 1.27 | 3.8 | 142.5 | ⌀14 | 2.3 | |
| KY80AS0404-30 | 48 | 400 | 3000 | 10.4 | 1.27 | 3.8 | 142.5 | ⌀14 | 2.3 | |
| KY80AS0407-30 | 48 | 700 | 3000 | 19.4 | 2.2 | 6.5 | 185 | ⌀14 | 3.5 | |
| 110*110mm | KY110AS0405-15 | 48 | 500 | 1500 | 14 | 3.1 | 10.8 | 199 | ⌀14 | 6 |
| KY110AS0205-15 | 24 | 500 | 1500 | 26 | 3.1 | 10.8 | 223 | ⌀14 | 6.6 | |
| KY110AS0408-15 | 48 | 800 | 1500 | 21 | 5 | 17.9 | 223 | ⌀14 | 6.6 | |
| KY110AS0207-15 | 24 | 750 | 1500 | 39 | 4.7 | 16.6 | 246 | ⌀19 | 7.6 | |
| KY110AS0408-25 | 48 | 800 | 2500 | 22 | 3 | 10.5 | 223 | ⌀14 | 6.6 | |
| KY110AS0410-15 | 48 | 1000 | 1500 | 26 | 6.3 | 22 | 246 | ⌀19 | 7.6 | |
| KY110AS0210-15 | 24 | 1000 | 1500 | 52 | 6.3 | 22 | 293 | ⌀22 | 10.2 | |
| KY110AS0412-25 | 48 | 1200 | 2500 | 31 | 4.5 | 15.7 | 246 | ⌀19 | 7.6 | |
| KY110AS0415-15 | 48 | 1500 | 1500 | 39 | 9.5 | 28 | 293 | ⌀19 | 10.2 | |
| KY110AS0415-30 | 48 | 1500 | 3000 | 30 | 4.7 | 14.1 | 246 | ⌀19 | 7.6 | |
| KY110AS0420-25 | 48 | 2000 | 2500 | 55 | 7.6 | 26 | 293 | ⌀22 | 10.2 | |
| 130*130mm | KY130AS0410-15 | 48 | 1000 | 1500 | 26 | 6.3 | 22 | 186 | ⌀25 | 7.6 |
| KY130AS0415-15 | 48 | 1500 | 1500 | 37.5 | 9.5 | 28 | 207 | ⌀28 | 13 | |
| KY130AS0430-15 | 48 | 3000 | 1500 | 73 | 19.1 | 57 | 273 | ⌀28 | 14.2 | |
We also can provide the matched gearbox for 48V 4KW BLDC MOTOR 1500RPM, to reduce the speed and get the higher torque.
Gear box range: line planetary gearbox, right angle planetary gearbox, worm gearbox, if you need other gearbox, kindly advise.
