75-inch conference all-in-one machine with camera

7 month ago
20 0
Product details
Product Description:

The 75-inch built-in camera conference all-in-one machine is a device that integrates a large-size display, built-in camera and other conference functions. It is mainly used for remote video conferencing, online training, remote collaboration, etc. in enterprises, education, government and other occasions. Here are some of its key features:

1. High-definition display: The 75-inch screen provides a wide field of view and clear images, suitable for conference scenarios where multiple people participate at the same time.

2. Built-in camera: The built-in high-definition camera supports full HD video capture to ensure the picture quality in video conferencing.

3. Audio system: It is usually equipped with a high-quality audio system, including microphones and speakers, to support two-way voice communication and improve meeting efficiency.

4. Integrated software and hardware: Many such devices are pre-installed with video conferencing software, such as Zoom, Microsoft Teams, Webex, etc., which allows users to conduct video conferencing directly through the device without installing additional software.

5. Ease of use: The design usually takes into account ease of use and human-computer interaction, and is equipped with an intuitive operating interface and remote control to facilitate operation by users of different technical levels.

6. Versatility: In addition to video conferencing, such devices may also support other functions such as file sharing, screen projection, and remote control to enhance the interactivity and productivity of meetings.

The 75-inch all-in-one conference machine with built-in camera is an efficient tool in the modern office environment, which can improve the quality and efficiency of remote communication and save time and cost.
Jiangsu Qilong Electronic Technology Co.,LTD.is a factory located in China. Specialized in producing Education Interactive Board, such as Interactive conference board, Memory blackboard, Smart blackboard,Training Interactive Board,etc.

Main specification parameters

1.  Overview of specifications


Faceplate Screen size 75"
Backlit type D-LED
Resolution ratio 3840*2160
Luminance ≥350cd/m²
Screen contrast 5000:1
Response time 6ms
Pixel point distance 0.42975×0.42975 mm (H×V) mm
Frame frequency 60 Hz
Angle of view 178°(H) / 178°(V)
Color saturation (x% NTSC) 72 %
Visual area 1650.24×928.26 mm (H×V) mm
Color degree 1.07B(8bit)
Life span 30,000 hrs
Programmatic Slug T982
System Properties System version Android 11.0
CPU Quad-core ARM Cortex-A55
GPU Mali-G52 MP2(2EE)
Internal cache capacity (RAM) 4 GB DDR4
Internal Storage Capacity (ROM) 32 GB Standard
Power parameters Voltage 100 V ~ 240 V/AC, 50/60 Hz
Maximum power (without OPS) ≦228W
OPS source 19V(DC)/5A
Power parameters Standby power consumption <0.5W
Power supply (AC) input *1
Built-in camera / pickup mic Maximum effective pixel 3840 * 3380 (13 megapixels, downward compatible
Camera dual system follow recognition Including 8 built-in array sound pickup mic, support the camera module
Pickup valid receiving distance 10 m (high sensitivity [-38 dB of 94 dB SPL @ 1 KHz]
Signal-to-noise ratio of the pick up 61dB of(94 dB SPL@1KHz,A-weighted)
Support function Echo cancellation / beamforming / removal conference room mixing to maintain voice reduction and voice recognition / automatic gain-AGC gentle high voice enhanced bass provides a consistent near and far call experience
Front interface Switch button * 1    (Light sense optional)
USB(Shared) * 3 Standard USB Type-A interface
Type-c USB*1 Standard USB3.0 Type-C interface
HDMI IN*1 Standard HDMI Type-A interface, and the HDMI input is displayed
TOUCH_OUT*1 Standard USB2.0 Type-B interface
Structure Net weight 54Kg±1.5Kg
Rough weight 60Kg±1.5Kg(Heavy Carton)
Bare machine size (length * width * thick) 1710mm*1037.6mm*89.6mm
Packaging size (length * width * height)    1850mm * 1150mm * 205mm (heavy duty carton)
VESA hole site    4-M8 screw hole 500mmx400mm
Housing Material (face frame / rear housing) Aluminum profile / sheet metal
Shell color (face frame / rear shell) Black (upper / lower silver / all silver optional)
Touch parameters Touch specifications Infrared touch box
Glass specifications General Glass / anti-glare toughened glass is available
Response speed    ≤6ms
Touch accuracy The accuracy of 90% center area is ± 1mm, and 10% edge area is ± 3mm
Touch parameters Touch diameter ≥3mm
Input mode Finger or special pen
Number of theoretical clicks Infinite times
Interface type The USB 2.0 is at full speed
Operating voltage 4.75~5.25V
Power wastage ≤2 W

Display:
75-inch Z8 all-in-one conference machine with built-in camera
