86-inch conference all-in-one machine

7 month ago
19 0
Product details
Product Description:

Driven by modern technology, our lives and work are being changed by intelligent and digital devices. Today, we introduce you to an advanced device that integrates high-definition display, interactive operation, and multi-functional integration - an 86-inch interactive integrated machine.

This 86-inch interactive integrated machine uses the latest generation of 4K UHD display technology to provide ultra-high-definition picture quality, whether it is watching movies, browsing pictures or displaying documents, it can present stunning visual effects. Its screen size reaches an astonishing 86 inches, whether in a home entertainment center, educational institution, conference room or commercial exhibition space, it can easily attract the attention of all audiences.

Interactivity is a highlight of this machine. It has built-in advanced touch technology and supports multi-touch operation. Whether it is gesture control, dragging files or writing notes, it can achieve a smooth and accurate operation experience. In addition, it is also equipped with a highly sensitive infrared sensor, which can ensure the responsiveness and accuracy of the user interface even on a larger screen, making the interaction more natural and efficient.

This 86-inch interactive integrated machine also has a wealth of interfaces, including USB, HDMI, VGA, etc., which can easily connect to various external devices such as computers, cameras, microphones, etc., to meet the needs of use in different scenarios. Whether it is a remote meeting, online teaching, or a multimedia presentation, it can be seamlessly connected and provide comprehensive support.

In terms of design, the machine adopts a modern and simple style, with an extremely narrow frame, providing a larger display area. Its sturdy body structure can withstand the wear and tear of daily use and is easy to clean and maintain. In addition, it also supports wall-mounted installation or desktop placement, which can be flexibly selected according to the actual environment, saving space while improving aesthetics.

In short, the 86-inch interactive integrated machine has become an all-round solution with its excellent display effect, powerful interactive functions, rich interface configurations and flexible installation methods. It is suitable for various occasions that require high-quality display and interactive experience. Whether it is to enhance the home entertainment experience or enhance the effect of education and business communication, it is an ideal choice.
Jiangsu Qilong Electronic Technology Co.,LTD.is a factory located in China. Specialized in producing Education Interactive Board, such as Interactive conference board, Memory blackboard, Smart blackboard,Training Interactive Board,etc.
Main specification parameters

1.  Overview of specifications

Faceplate Screen size 86"
Backlit type D-LED
Resolution ratio 3840*2160
Luminance ≥350cd/m²
Screen contrast 6400:1
Response time 6ms
Pixel point distance 0.4875 mm x 0.4875 mm (H×V)
Frame frequency 60 Hz
Angle of view 178°(H) / 178°(V)
Color saturation (x% NTSC) 72 %
Visual area 1872(H)x1053(V)mm
Color degree 1.07B(8bit)
Life span 30,000 hrs
Project Slug GK6760V100
System Properties System version Android 12.0
CPU 8*A55
GPU Mali-G52 MP2(2EE)
Internal cache capacity (RAM) 4 GB DDR4
Internal Storage Capacity (ROM) 32 GB Standard
Power parameters Voltage 100 V ~ 240 V/AC, 50/60 Hz
Maximum power (without OPS) ≦326W
OPS source 19V(DC)/5A
Power parameters Standby power consumption <0.5W
Power supply (AC) input *1
Structure Net weight 70Kg±1.5Kg
Rough weight 78Kg±1.5Kg(Heavy Carton)
Bare machine size (length * width * thick) 1934.8mm*1149.1mm*89.6mm
Packaging size (length * width * height) 2080mm*1280mm*205mm(Heavy Carton)
VESA hole site 4-M8 screw hole of 500mmx400mm
Housing Material (face frame / rear housing) Aluminum profile / sheet metal
Shell color (face frame / rear shell) Black (upper / lower silver / all silver optional)
Front interface Switch button * 1    (Light sense optional)
USB(Shared) * 3 Standard USB Type-A interface
Type-c USB*1 Standard USB3.0 Type-C interface
HDMI IN*1 Standard HDMI Type-A interface, and the HDMI input is displayed
TOUCH_OUT*1 Standard USB2.0 Type-B interface
Touch parameters Touch specifications Infrared touch box
Glass specifications General Glass / anti-glare toughened glass is available
Response speed    ≤6ms
Touch accuracy The accuracy of 90% center area is ± 1mm, and 10% edge area is ± 3mm
Touch parameters Touch diameter ≥3mm
Input mode Finger or special pen
Number of theoretical clicks Infinite times
Interface type The USB 2.0 is at full speed
Operating voltage 4.75~5.25V
Power wastage ≤2 W
