98-inch conference all-in-one machine

7 month ago
18 0
Product details
98-inch digital smart interactive whiteboard: opening a new era of education and collaboration

In the field of modern education and corporate collaboration, technology is driving the transformation of traditional models at an unprecedented speed. As a leader in this wave of change, the 98-inch digital smart interactive whiteboard has become the preferred tool for educators and business leaders with its excellent performance, advanced technology and user-friendly design. It not only improves the efficiency of teaching and meetings, but also greatly enriches the interactive experience, making knowledge dissemination and information sharing more vivid and interesting.

High-definition display and wide viewing angle

The 98-inch digital smart interactive whiteboard uses a high-resolution display to provide clear and delicate picture presentation, whether it is complex charts, high-definition videos or detailed handwritten notes, it can be displayed with extremely high fidelity. Its wide viewing angle design ensures that no matter where you stand in the room, you can get a consistent visual experience, avoiding the problem of picture distortion caused by different angles.

Intelligent interaction and multi-touch

This whiteboard supports multi-touch operation, without the need for special pens or tools, you can easily write, draw, drag and zoom with just your fingers. The built-in intelligent recognition system can accurately capture hand movements to achieve a smooth and natural interactive experience. In addition, it also supports gesture recognition, such as erasing, zooming in, rotating, etc., which greatly improves work efficiency.

Integration of education and conference functions

This whiteboard is not only an efficient display tool, but also a comprehensive platform that integrates multimedia playback, electronic whiteboard, document editing, remote collaboration and other functions. It is compatible with files in various formats and supports wireless screen projection, making remote teaching and meetings more convenient. Teachers can easily share PPT, video, audio and other resources in class, and students can deepen their understanding and enhance their learning interest through interaction.

System integration and ease of use

The 98-inch digital intelligent interactive whiteboard provides a wealth of preset templates and quick operation options through a simple and intuitive user interface, so that even first-time users can quickly get started. It supports multiple operating systems, such as Windows, macOS and Linux, to ensure seamless integration with existing office environments, reducing training costs and usage barriers.

Security and stability

Considering the particularity of education and enterprise applications, this whiteboard adopts high-standard security protection measures to ensure the stability and security of data transmission. At the same time, its durable design ensures reliability over long periods of use, reducing maintenance costs and downtime.

Jiangsu Qilong Electronic Technology Co.,LTD.is a factory located in China. Specialized in producing Education Interactive Board, such as Interactive conference board, Memory blackboard, Smart blackboard,Training Interactive Board,etc.
Main specification parameters

1.  Overview of specifications

Faceplate Screen size 98"
Backlit type D-LED
Resolution ratio 3840*2160
Luminance ≥350cd/m²
Screen contrast 1200:1
Response time 6ms
Pixel point distance 0.5622×0.5622 mm (W×H)
Frame frequency 60 Hz
Angle of view 178°(H) / 178°(V)
Color saturation (x% NTSC) 72 %
Visual area 2158.85(W)×1214.35(H) mm
Color degree 1.07B(8bit)
Life span 30,000 hrs
Project Slug GK6760V100
System Properties System version Android 12.0
CPU 8*A55
GPU Mali-G52 MP2(2EE)
Internal cache capacity (RAM) 4 GB DDR4
Internal Storage Capacity (ROM) 32 GB Standard
Power parameters Voltage 100 V ~ 240 V/AC, 50/60 Hz
Maximum power (without OPS) ≦449W
OPS source 19V(DC)/5A
Power parameters Standby power consumption <0.5W
Power supply (AC) input *1
Structure Net weight 110Kg±1.5Kg
Rough weight 120Kg±1.5Kg(Heavy Carton)
Bare machine size (length * width * thick) 2218.4mm*1306.7mm*93.2mm
Packaging size (length * width * height) 2325mm*1445mm*220mm(Heavy Carton)
VESA hole site 4-M8 screw hole 800mmx500mm
Housing Material (face frame / rear housing) Aluminum profile / sheet metal
Shell color (face frame / rear shell) Black (upper / lower silver / all silver optional)
Front interface Switch button * 1    (Light sense optional)
USB(Shared) * 3 Standard USB Type-A interface
Type-c USB*1 Standard USB3.0 Type-C interface
HDMI IN*1 Standard HDMI Type-A interface, and the HDMI input is displayed
TOUCH_OUT*1 Standard USB2.0 Type-B interface
Touch parameters Touch specifications Infrared touch box
Glass specifications General Glass / anti-glare toughened glass is available
Response speed    ≤6ms
Touch accuracy The accuracy of 90% center area is ± 1mm, and 10% edge area is ± 3mm
Touch parameters Touch diameter ≥3mm
Input mode Finger or special pen
Number of theoretical clicks Infinite times
Interface type The USB 2.0 is at full speed
Operating voltage 4.75~5.25V
Power wastage ≤2 W

Display:
98-inch Z8 conference all-in-one machine98-inch Z8 conference all-in-one machine
