86-inch conference all-in-one machine with carema

7 month ago

18 0 

Jiangsu Qilong Electronic Technology Co., Ltd.

9 month

Product details

Product Overview:
Interactive Smart Conference All-in-One Blackboard is a smart blackboard that integrates conference, education and collaboration functions. It is not only a traditional writing tool, but also a comprehensive digital solution designed to improve meeting efficiency, promote educational interaction and strengthen teamwork. This device combines advanced technology with humanized design to provide users with an efficient, convenient and creative working environment.

Main Features:

1. Smart touch technology: It adopts a highly sensitive capacitive touch screen and supports multi-touch. Users can write, draw, erase and other operations with their fingers or special pens, and experience the natural and smooth writing on a traditional blackboard.

2. Seamlessly integrated software: It has built-in multiple office software and applications, such as presentations, whiteboard applications, video conferencing systems, etc., supports wireless projection, and easily realizes content sharing and remote collaboration.

3. High-definition display: Equipped with a high-resolution display, whether it is showing complex charts, high-definition videos or delicate images, it can be presented clearly to ensure that every participant can get the best visual experience.

4. Audio Enhancement: Built-in high-quality sound system, support voice amplification and echo cancellation functions, ensure that every corner of the conference room can hear clear sound.

5. Smart whiteboard function: Supports saving and sharing meeting records, including handwritten notes, presentation content, etc., for subsequent review and editing.

6. Environmental protection and energy saving: Adopting low-energy consumption design, it can maintain efficient operation after long-term use, reduce energy consumption, and conform to the concept of sustainable development.

7. Easy to install and maintain: The design is simple and easy to install in any conference room or classroom. At the same time, it provides comprehensive technical support and maintenance services to ensure the long-term stable operation of the equipment.

8. Multi-function expansion: Through the interface, it supports the connection of external devices such as cameras, printers, etc. to meet the needs of different scenarios.

Applicable to various occasions:

- Corporate meetings: Improve meeting efficiency and promote team communication and collaboration.

- Education: Enhance teaching interactivity, improve student participation and learning effects.

- Remote work: Support remote team meetings, break geographical restrictions, and achieve seamless collaboration.
- Training and Seminars: Provide flexible presentation and interactive space to meet the needs of events of different sizes.

Interactive Smart Conference All-in-One Blackboard, with its innovative functions and excellent performance, has become an indispensable tool in modern work, education and collaboration environments, and is committed to creating a more efficient, interactive and green work and learning environment.

Jiangsu Qilong Electronic Technology Co.,LTD.is a factory located in China. Specialized in producing Education Interactive Board, such as Interactive conference board, Memory blackboard, Smart blackboard,Training Interactive Board，etc.

Main specification parameters

1. Overview of specifications

Faceplate	Screen size	86"
	Backlit type	D-LED
	Resolution ratio	3840*2160
	Luminance	≥350cd/m²
	Screen contrast	6400:1
	Response time	6ms
	Pixel point distance	0.4875 mm x 0.4875 mm (H×V)
	Frame frequency	60 Hz
	Angle of view	178°(H) / 178°(V)
	Color saturation (x% NTSC)	72 %
	Visual area	1872（H）x1053（V）mm
	Color degree	1.07B(8bit)
	Life span	30,000 hrs
Project	Slug	GK6760V100
System Properties	System version	Android 12.0
	CPU	8*A55
	GPU	Mali-G52 MP2(2EE)
	Internal cache capacity (RAM)	4 GB DDR4
	Internal Storage Capacity (ROM)	32 GB Standard
Power parameters	Voltage	100 V ~ 240 V/AC, 50/60 Hz
	Maximum power (without OPS)	≦326W
	OPS source	19V(DC)/5A
Power parameters	Standby power consumption	<0.5W
Power parameters	Power supply (AC) input	*1
Built-in camera / pickup mic	Maximum effective pixel	3840 * 3380 (13 megapixels, downward compatible
	Camera dual system follow recognition	Including 8 built-in array sound pickup mic, support the camera module
	Pickup valid receiving distance	10 m (high sensitivity [-38 dB of 94 dB SPL @ 1 KHz]
	Signal-to-noise ratio of the pick up	61dB of（94 dB SPL@1KHz,A-weighted）
	Support function	Echo cancellation / beamforming / removal conference room mixing to maintain voice reduction and voice recognition / automatic gain-AGC gentle high voice enhanced bass provides a consistent near and far call experience


Front interface	Switch button * 1	(Light sense optional)
	USB(Shared) * 3	Standard USB Type-A interface
	Type-c USB*1	Standard USB3.0 Type-C interface
	HDMI IN*1	Standard HDMI Type-A interface, and the HDMI input is displayed
	TOUCH_OUT*1	Standard USB2.0 Type-B interface
Structure	Net weight	70Kg±1.5Kg
	Rough weight	78Kg±1.5Kg (Heavy-duty carton)
	Bare machine size (length * width * thick)	1934.8mm1164.1mm89.6mm
	Packaging size (length * width * height)	2080mm * 1280mm * 205mm (heavy duty carton
	VESA hole site	4-M8 screw hole of 500mmx400mm
	Housing Material (face frame / rear housing)	Aluminum profile / sheet metal
	Shell color (face frame / rear shell)	Black (upper / lower silver / all silver optional)
Touch parameters	Touch specifications	Infrared touch box
	Glass specifications	General Glass / anti-glare toughened glass is available
	Response speed	≤6ms
	Touch accuracy	The accuracy of 90% center area is ± 1mm, and 10% edge area is ± 3mm
Touch parameters	Touch diameter	≥3mm
	Input mode	Finger or special pen
	Number of theoretical clicks	Infinite times
Interface type	The USB 2.0 is at full speed
Operating voltage	4.75～5.25V
Power wastage	≤2 W

Display:
