98-inch conference all-in-one machine

7 month ago
17 0
Product details
Product Description:

98 Inch Interactive Smart Board is a large-screen interactive smart whiteboard that integrates multiple functions such as conference, teaching, and demonstration. It uses a 98-inch ultra-large screen with a resolution of up to 3840*2160. The display effect is very clear and delicate, which can meet the needs of large-scale conferences, teaching and other occasions.

The smart whiteboard also uses advanced capacitive touch technology and supports multi-touch. Users can operate it in various ways such as fingers and pens. It has very high sensitivity and fast response speed. At the same time, it is also equipped with a variety of input and output interfaces, such as HDMI, USB, VGA, etc., which can easily connect external devices such as computers and projectors to achieve multiple functions.

In addition,  98 Inch Interactive Smart Board also has a variety of practical functions, such as file transfer, screen recording, remote control, etc., which can improve the efficiency and quality of conferences, teaching and other activities. In addition, it also supports multiple people to use at the same time, which can realize multi-person collaboration, making conferences, teaching and other activities more vivid and interactive.

In short, Conference Solution 98 Inch Interactive Smart Board is a large-screen interactive smart whiteboard with complete functions, easy operation and excellent effects. It is suitable for various occasions and is an ideal choice for improving the efficiency of meetings, teaching and other activities.
Jiangsu Qilong Electronic Technology Co.,LTD.is a factory located in China. Specialized in producing Education Interactive Board, such as Interactive conference board, Memory blackboard, Smart blackboard,Training Interactive Board,etc.
Main specification parameters

1.  Overview of specifications

Faceplate Screen size 98"
Backlit type D-LED
Resolution ratio 3840*2160
Luminance ≥350cd/m²
Screen contrast 1200:1
Response time 6ms
Pixel point distance 0.5622×0.5622 mm (W×H)
Frame frequency 60 Hz
Angle of view 178°(H) / 178°(V)
Color saturation (x% NTSC) 72 %
Visual area 2158.85(W)×1214.35(H) mm
Color degree 1.07B(8bit)
Life span 30,000 hrs
Project Slug MSD6190

Power parameters Voltage 100 V ~ 240 V/AC, 50/60 Hz
Maximum power (without OPS) ≦449W
OPS source 19V(DC)/5A
Power parameters Standby power consumption <0.5W
Power supply (AC) input *1
Structure Net weight 110Kg±1.5Kg
Rough weight 120Kg±1.5Kg (Heavy-duty carton)
Bare machine size (length * width * thick) 2218.4mm*1306.7mm*93.2mm
Packaging size (length * width * height) 2325mm * 1445mm * 220mm (heavy duty carton)
VESA hole site 4-M8 screw hole 800mmx500mm
Housing Material (face frame / rear housing) Aluminum profile / sheet metal
Shell color (face frame / rear shell) Black (upper / lower silver / all silver optional)
Front interface Switch button * 1    (Light sense optional)
USB(Shared) * 3 Standard USB Type-A interface
Type-c USB*1 Standard USB3.0 Type-C interface
HDMI IN*1 Standard HDMI Type-A interface, and the HDMI input is displayed
TOUCH_OUT*1 Standard USB2.0 Type-B interface
Touch parameters Touch specifications Infrared touch box
Glass specifications General Glass / anti-glare toughened glass is available
Response speed    ≤6ms
Touch accuracy The accuracy of 90% center area is ± 1mm, and 10% edge area is ± 3mm
Touch parameters Touch diameter ≥3mm
Input mode Finger or special pen
Number of theoretical clicks Infinite times
Interface type The USB 2.0 is at full speed
Operating voltage 4.75~5.25V
Power wastage ≤2 W

Display:
98-inch Z8 conference all-in-one machine98-inch Z8 conference all-in-one machine
