75 inch Infrared touch one machine

7 month ago
18 0
Product details
Product Description:
In modern education and office environments, the integration of technology is changing the way we learn and work at an unprecedented speed. As a high-end device that integrates display, writing, interaction and collaboration functions, the Office 75-inch fully integrated interactive whiteboard not only provides users with a new information exchange platform, but also promotes the innovation of teaching and office methods.

Product Features:

1. 75-inch ultra-large screen: Using high-definition resolution display technology, it provides a wide field of view and delicate pictures, ensuring that every participant can clearly see the content on the screen, whether it is a remote meeting or a large lecture.

2. Fully integrated design: Integrating whiteboard, projector, audio, touch screen and other functions into one, greatly saving space, while simplifying the layout and management of equipment, making the office or classroom more tidy and efficient.

3. Interactive writing experience: Supporting multi-touch, users can write, draw and annotate directly on the screen with their fingers or special pens to achieve a natural and smooth interactive experience. This non-contact operation method reduces the risk of virus transmission and is particularly suitable for the current public health environment.

4. Wireless connection and sharing: Supports wireless screen projection of multiple devices, whether it is a mobile phone, tablet or computer, it can easily share content on the big screen, promote remote collaboration and interaction, and greatly improve team work efficiency.

Advantages summary:

- Improve efficiency and convenience: Integrated design and intelligent operation greatly improve work efficiency and reduce the complexity of use.

- Enhance interactivity: Rich interactive functions promote interaction between participants and stimulate the enthusiasm for learning and work.

- Health and safety: Non-contact operation reduces the health risks caused by physical contact, which is particularly suitable for current public health needs.
Jiangsu Qilong Electronic Technology Co.,LTD.is a factory located in China. Specialized in producing Education Interactive Board, such as Interactive conference board, Memory blackboard, Smart blackboard,Training Interactive Board,etc.



Overview of specifications
Face plate Screen size 75"
Backlit type D-LED
Resolution ratio 3840*2160
Luminance ≥350cd/m²
Screen contrast 5000:1
Response time 6ms
Pixel point distance 0.42975 mm x 0.42975 mm (H×V)
Frame frequency 60 Hz
Angle of view 178°(H) / 178°(V)
Color saturation (x% NTSC) 72%
Visual area 1650.24(H)x928.26(V)mm
Color degree 1.07B(8bit)
Life span 30,000hrs
System Properties System version Android 12.0
CPU 8*A55
GPU Mali-G52 MP2(2EE)
Internal cache capacity (RAM) 4GBDDR4
Internal Storage Capacity (ROM) 32GB Standard
Power parameters Voltage 100 V ~ 240 V/AC, 50/60 Hz
Maximum power (without OPS) ≦228W
OPS source 19V(DC)/5A
Power parameters Standby power consumption <0.5W
Power supply (AC) input *1
Front interface Switch button * 1 Light sense is optional
USB (shared) * 3 Standard USB Type-A interface
Type-c USB*1    Standard USB2.0 Type-C interface
HDMI IN*1    Standard HDMI Type-A interface, and the HDMI input is displayed
TOUCH_OUT*1 Standard USB2.0 Type-B interface
Structure Net weight    54Kg±1.5Kg
Rough weight    60Kg±1.5Kg(Heavy Carton)
Bare machine size (length * width * thick) 1710mm*1022.6mm*89.6mm
Packaging size (length * width * height) 1850mm*1150mm*205mm(Heavy Carton)
VESA hole site 4-M8 screw hole of 500mmx400mm
Housing Material (face frame / rear housing) Aluminum profile / sheet metal
Shell color (face frame / rear shell)    Black (upper / lower silver / all silver optional)
Language OSD menu Simplified Chinese / Traditional / English / Korean
Main specifications and parameters

Touch parameters


Touch specifications
Infrared touch box
Glass specifications
General Glass / anti-glare toughened glass
response speed
≤6ms
Touch accuracy
The accuracy of 90% center area is ± 1mm, and 10% edge area is ± 3mm

Touch parameters

Touch the diameter
≥3mm
input mode
Finger or special pen
Number of theoretical clicks
Infinite times
Interface type
USB 2.0  full speed
Touch parameters
4.75~5.25V
Interface type
≤2 W

Display:
75-inch Z8 conference all-in-one machine
