86-inch Z8 all-in-one conference machine (YS982)
7 month agoAudio and video system: Equipped with high-quality speakers and microphones, it supports 360-degree omnidirectional sound pickup to ensure that the sound in the conference room is clear and discernible, and has good sound performance, which is suitable for remote video conferencing.
Energy saving and environmental protection: Modern all-in-one conference machines usually use LED backlight technology, which can significantly reduce energy consumption and reduce the impact on the environment compared to traditional LCD or CRT screens.
Customized service: According to different application scenarios and needs, manufacturers provide customized solutions, such as different sizes and configurations, as well as special function integration for specific industries (such as medical and education).


Overview of specifications | ||
Face plate | Screen size | 86" |
Backlit type | D-LED | |
Resolution ratio | 3840*2160 | |
Luminance | ≥350cd/m² | |
Screen contrast | 6400:1 | |
Response time | 6.5ms | |
Pixel point distance | 0.4875 mm x 0.4875 mm (H×V) | |
Frame frequency | 60 Hz | |
Angle of view | 178°(H) / 178°(V) | |
Color saturation (x% NTSC) | 72% | |
Visual area | 1872(H)x1053(V)mm | |
Color degree | 1.07B(8bit) | |
Life span | 30,000hrs | |
System Properties | System version | Android 11.0 |
CPU | Quad-core ARM Cortex-A55 | |
GPU | Mali-G52 MP2(2EE) | |
Internal cache capacity (RAM) | 4GBDDR4 | |
Internal Storage Capacity (ROM) | 32GB Standard | |
Power parameters | Voltage | 100 V ~ 240 V/AC, 50/60 Hz |
Maximum power (without OPS) | ≦326W | |
OPS source | 19V(DC)/5A | |
Power parameters | Standby power consumption | <0.5W |
Power supply (AC) input | *1 | |
Front interface | Switch button * 1 | Light sense is optional |
USB (shared) * 3 | Standard USB Type-A interface | |
Type-c USB*1 | Standard USB3.0 Type-C interface | |
HDMI IN*1 | Standard HDMI Type-A interface, and the HDMI input is displayed | |
TOUCH_OUT*1 | Standard USB2.0 Type-B interface | |
Structure | Net weight | 70Kg±1.5Kg |
Rough weight | 78Kg±1.5Kg(Heavy Carton) | |
Bare machine size (length * width * thick) | 1934.8mm*1149.1mm*89.6mm | |
Packaging size (length * width * height) | 2080mm*1280mm*205mm(Heavy Carton) | |
VESA hole site | 4-M8 screw hole of 500mmx400mm | |
Housing Material (face frame / rear housing) | Aluminum profile / sheet metal | |
Shell color (face frame / rear shell) | Black (upper / lower silver / all silver optional) | |
Language | OSD menu | Simplified Chinese / Traditional / English / Korean |
Main specifications and parameters | ||
Touch parameters |
Touch specifications |
Infrared touch box |
Glass specifications |
General Glass / anti-glare toughened glass | |
response speed |
≤6ms | |
Touch accuracy |
The accuracy of 90% center area is ± 1mm, and 10% edge area is ± 3mm | |
Touch parameters |
Touch the diameter |
≥3mm |
input mode |
Finger or special pen | |
Number of theoretical clicks |
Infinite times | |
Interface type |
USB 2.0 full speed |
|
Touch parameters |
4.75~5.25V |
|
Interface type |
≤2 W |
