75-inch Z8 built-in camera conference machine spec

7 month ago
16 0
Product details
What is one advantage of using an interactive whiteboard?
Unlike document sharing, interactive whiteboard users can make lasting and effective changes to documents during a session. The tools included with the whiteboard allow for 3D modeling, estimation, hyperlinks, video links, and other applications that can improve communication and make documents more powerful.

Why is the whiteboard effective?
Whiteboards are a great tool in the classroom because they allow students to collaborate more effectively, reinforce concepts with charts and illustrations, and create presentations for class discussions or lectures. Overall, whiteboards allow teachers to effectively engage students through hands-on practice.
75-inch Z8 all-in-one conference machine with built-in camera75-inch Z8 all-in-one conference machine with built-in camera75-inch Z8 all-in-one conference machine with built-in camera
In addition, Interactive tablet, Conference interactive tablet, Multimedia All-in-One PC, etc. are all our company's main products. If you need it, please contact us

Main specification parameters

1.  Overview of specifications


Faceplate Screen size 75"
Backlit type D-LED
Resolution ratio 3840*2160
Luminance ≥350cd/m²
Screen contrast 5000:1
Response time 6ms
Pixel point distance 0.42975×0.42975 mm (H×V) mm
Frame frequency 60 Hz
Angle of view 178°(H) / 178°(V)
Color saturation (x% NTSC) 72 %
Visual area 1650.24×928.26 mm (H×V) mm
Color degree 1.07B(8bit)
Life span 30,000 hrs
Programmatic Slug T982
System Properties System version Android 11.0
CPU Quad-core ARM Cortex-A55
GPU Mali-G52 MP2(2EE)
Internal cache capacity (RAM) 4 GB DDR4
Internal Storage Capacity (ROM) 32 GB Standard
Power parameters Voltage 100 V ~ 240 V/AC, 50/60 Hz
Maximum power (without OPS) ≦228W
OPS source 19V(DC)/5A
Power parameters Standby power consumption <0.5W
Power supply (AC) input *1
Built-in camera / pickup mic Maximum effective pixel 3840 * 3380 (13 megapixels, downward compatible
Camera dual system follow recognition Including 8 built-in array sound pickup mic, support the camera module
Pickup valid receiving distance 10 m (high sensitivity [-38 dB of 94 dB SPL @ 1 KHz]
Signal-to-noise ratio of the pick up 61dB of(94 dB SPL@1KHz,A-weighted)
Support function Echo cancellation / beamforming / removal conference room mixing to maintain voice reduction and voice recognition / automatic gain-AGC gentle high voice enhanced bass provides a consistent near and far call experience
Structure Net weight 54Kg±1.5Kg
Rough weight 60Kg±1.5Kg(Heavy Carton)
Bare machine size (length * width * thick) 1710mm*1037.6mm*89.6mm
Packaging size (length * width * height)    1850mm*1150mm*205mm(Heavy Carton)
VESA hole site    4-M8 screw hole 500mmx400mm
Housing Material (face frame / rear housing) Aluminum profile / sheet metal
Shell color (face frame / rear shell) Black (upper / lower silver / all silver optional)
Touch parameters Touch specifications Infrared touch box
Glass specifications General Glass / anti-glare toughened glass is available
Response speed    ≤6ms
Touch accuracy The accuracy of 90% center area is ± 1mm, and 10% edge area is ± 3mm
Touch parameters Touch diameter ≥3mm
Input mode Finger or special pen
Number of theoretical clicks Infinite times
Interface type  USB 2.0  full speed
Operating voltage 4.75~5.25V
Power wastage ≤2 W

Display:
75-inch Z8 all-in-one conference machine with built-in camera
