Rocker switch

the aesthetics and ergonomics into the consideration, so that the operation will be easier and convenient.

Our X5 Auto Rocker switch is IP67 waterproof rating, it is CUL & ENEC certificate . X5 Rocker Switch is 1,2 pole circuitry.

Specification:

• Safety approved internationally by cURus in North America, ENEC15 in Europe.
• 1, 2 pole circuitry; 2 and 3 positions, maintained and momentary action
• Optional actuator type and marking.
• Environment-proof sealing, confirming to IP67 level
• Quick-connect, solder and screwed terminals
• Panel accessories as optional parts
• Application includes automotive, marine, agriculture machine and more.

A wide range of temperature rating, confirming to μ40T85/55

• 16(8)A 125/250V, ~µT55, ~µ40T85/55, 1E4, 50/60Hz  (cURus, ENEC15)
• 20(8)A 125/250V, ~µT55,~µ40T85/55, 1E4, 50/60Hz  (cURus, ENEC15)
• 16A DC, 6V, 12V, 14V, 18V, 24V, 30V, µT55, µ40T85/55, 1E4, 50/60Hz  (cURus, ENEC15)
• Electrical life:6,000 cycles(cURus), 10,000 cycles  (ENEC15)
• Dielectric strength: 1,500 VAC for 1 minute
• Initial contact resistance: 20m Ohms max.

Insulation resistance: 100M Ohms min, at 500VDC

How to order

Panel cutout
