5 year agoThreaded Brass Male Plug
-
Description:Threaded Brass Male Plug used to join to the fluid transfer line for seal.
The brass plug is mainly for pipe seal.To make sure no leakage,ours is thicker.
The brass fittings know as brass plumbing fittings,brass pipe fittings,EN1254 brass fittings and brass pressure fittings is popular for its machining performance.The quality can match to connex brass fittings,yorkshire brass fittings,pegler brass fittings.the threaded brass male plug is same as threade end cap .as one of brass fittings ,it is mainly used for pipe seal.And we have other solder ring brass fittings(SR brass fittings) and end feed brass fittings(EF brass fittings) for your selection.
-
Production Standard:
1.EN1254-1:1998/BS864-2(Copper And Copper Alloys-Plumbing Fittings)
2.ISO228-1 Pipe Threads Where Pressure-tight joints are not made on the threads
3.ISO 7-1(EN10226-1&2 R,Rp,Rc) Pipe threads where presssure-tight joints are made on the threads- Part 1:Dimensions,tolerances and designation
4.ASME B1.20.1 Pipe Threads,General Purpose(Inch)
-
Material:
HPb59-1
Cu57-60% Al≤0.2% Fe≤0.5% Pb 0.8-1.9% Sb≤0.01% Bi≤0.003% P≤0.02% Zn balance
CW617N(CuZn40Pb2)
Cu57-59% Al≤0.05% Fe≤0.3% Pb 1.6-2.5% Sn≤0.3% Ni≤0.3% Sn≤0.3% Zn balance
CC754S(CuZn39Pb1Al-C)
Cu58-62% Sn≤1% Al0.1-0.8% Fe≤0.7% Pb 0.5-2.4% Ni≤1% Mn≤0.5% P≤0.02% Si≤0.05% Zn balance
CW724R(CuZn21SI3P for Press Fittigs)
Cu75-77% Al≤0.05% Fe≤0.3% Mn≤0.05 P0.02-0.1% Pb ≤0.1% Si 2.7-3.5% Sn≤0.3% Ni≤0.2% Sn≤0.3% Zn balance
C37700
Cu58-61% Pb1.5-2.5% Fe≤0.3% Zn Balance
DZR602(CuZn36Pb2As-CW602N)
Cu60-63% Sn≤0.3% Al0.3-0.5% Fe≤0.3% Pb 1-2.5% As 0.08-0.15% Zn balance
-
Application: Industrial or Residential Water and plumbing,drinking supply,cold and hot water supply, heating supply, fire protection,gas supply, industrial petroleum pipeline system etc.Suit Medium:Cold Water, Hot Water Etc.
