IP68 16MM Metal Pushbutton Switch
The series pushbuton switch has alread passed CQC/CE/SGS/REACH/TUV certificate.
Product parameters
Panel Cutout: 16mm Diameter Max.Switch Rating: 4A 32V AC Switch Combination: NO-OFF Operation Type: reset type Housing material: plastic Light shape: Overall luminous Base: PA66 Operating pressure: 350gf-80gf Travel: 2.8mm ± 0.5mm |
Contact resistance: 50Ω Max(initial) Insulation resistance: 100MΩ Min Dielectric strength: 2000VAC for 1 Minute Temperature: -20 ° C to 85 ° C LED Ratde voltage: 1.8V/3V/6V/12V/24V/36V 48V/110V/220V ILLUMINATION BASE RATlNG: Red, Yellow and Orange: 20mA 1.8V; Blue, Green and White: 20mA 2.8V |

Our Advantages
From the purchase of raw materials to the finished product, all production process (product development/plating/mold and equipment processing/ metalpressing/ plasticinjection/semi-automatic and fully automated equipment assembly, etc.) are completed in the factory. Our metal pressing and plastic injection own the advantages of 100% self-made mold, from a single form to the various forms of application. And we continuously keep innovation and enhance the technology in order to collaborate with our customers to design the most sophisticated products. Yeswitch Electronics Co., Ltd., whether in production base or in quality assurance department in the head office, have professional equipment and technical personnel. In addition to the annual new product development, product improvement and testing are performed as annual plan to ensure that listed products maintain in best quality. Therefore, our long-term customers/partners, get the best quality of the switches.
