Multimedia All-in-One PC 1



1. Multi-theme system theme, provide conference, education, science and technology, welcome template, provide enterprise, government, medical care, education, advertising and other more than ten industry template applications, support multi-person sign-in, save, scan code sharing.
2, the signal source dynamic preview, static and dynamic wallpaper, can be clicked after the quick preview, change at will, and support custom wallpaper function.
3, a variety of energy saving ways, support screen dormancy, screen saver mode, timing on and off.
4. It can monitor the temperature value of the whole machine in real time, and the temperature can be displayed on the Android home page, prompting different colors. Automatic close the whole machine when the temperature of the whole machine is too high.
5, multi-screen interaction, support 4 ios, android, pc, mac and other devices random screen.
6. Intelligent channel identification, automatically jump after inserting the signal source, and prompt the inquiry dialog box.
7, comprehensive safety lock function, provide U disk lock, screen lock, application software lock, touch lock.
8, image mode, provide the setting in the signal source channel, what you see is what you get, no need to exit the menu setting.
9, a variety of sound mode selection, provide the choice of sound device function, can choose the horn, USB microphone, etc., and support the equalizer function.
10. Adaptive ambient light function, which supports adjusting the screen brightness according to the ambient light, and the system supports the anti-blue light eye protection mode to protect the user's eyes.





Name	Size	110"
Show	Display Area	2436.5mm（H）×1370.5mm（V）
	Optimum Resolution	3840×2160 pixels
	Refresh the Frequency	60Hz
	Luminance	350-450cd/m2
	Contrast Ratio	1200:1
	Visual Angle	1780(H/V)
	Show Color	8bit 16.7M/1.07B (10bit)
	Backlight	DLED
	Colour gamut ntsc	72%
	Life Span	For 50,000 hours
Surface	Body material	Aluminum alloy face frame, oxidation sandblasting process
	Front frame color	Black [Standard]
	Front frame glass	Physical tempered grade 7 explosion-proof glass
	Front frame button	1-way two-color switch (three-in-one setting: energy saving, switch OPS computer, switch machine)
Touch parameters	Identification principle	Infrared recognition
	Touch embedding mode	Built-in integrated type
	The way of writing	Finger, touch pen or other 2mm non-transparent object (full screen writing)
	Number of touch points	At 20 o'clock
	Touch resolution	32767*32767
	Touch precision	±1mm
	Single refers to the response speed	＜8ms
	Touch number	The theoretical number is infinite
	Drivers	System automatic identification, no drive
	Support system	windowsXP /7/8/10/11，Android，MacOS，Linux
	Working Temperature	-10~+50 ℃
	Communication Mode	USB 2.0/USB 3.0
Size weight	Standard bare machine size is long	2503mm (length) * 109mm (width) * 1470mm (height) with OPS
	Camera model naked machine ruler	2503mm (length) * 109mm (width) * 1484mm (height) with OPS
	packing measurement	2685mm (length) * 285mm (width) * 1710 (height) (world cover)
	VESA stent hole position (mm)	700mm (height) 1600mm (long)
	Wall hanging thickness (mm)	36mm
	net weight	130KG
	rough weight	155KG
Complete machine power consumption	The power of the machine	≤880W
	OPS power	≤120W
	working voltage	100~240V AC, 50/60Hz
	Standby power consumption	≤0.5W
	Sound channel stereo	2.0
	Dual-channel power	15W / 8 O. 2 speakers
