Electric Rail Profile Grinding Machine
PRODUCT FEATURES
This machine is powered by the M165 two-stroke petrol engine imported from Spain. It is a small machine used for forming and grinding the rail head welding joints and surface repairs. It is suitable for rails of 43~75kg/m. The special diaphragm carburetor make sure the engine does not stall after turning 90°, and the output torque is stable without power attenuation, thus ensuring the precision of rail grinding.
TECHNICAL DATA
Engine
2 stroke petrol engine M165
Power
6.0kW
Grinding stone speed
≥3900r/min
Grinding stone inclination
0~90°
Grinding stone feeding stroke
42mm
Grinding stone specification
φ150xφ55x70mm
Fuel tank volume
4.5L
Profile wheel span
1000mm
Feed adjustment accuracy
0.125mm
Dimensions
1410x500x850mm
Weight
60kg
