DMF-T-62S BFEC 2 1/2'' Straight Through Dust Collector Pulse Jet Valve 24V 110V 220V

DMF-T-62S 2-1/2'' Inch Straight Through Pulse Jet Valve

Type:SOLENOID VALVES, Straight Throught Pulse Jet Valve
Place of Origin:China
Brand Name:Brando
Model Number:DMF-T-62S
Application:Dust Collector
Temperature of Media:Medium Temperature
Power:SOLENOID
Media:Air
Port Size:2-1/2 Inch
Structure:Diaphragm
Voltage:AC220V, AC110V, AC24V, DC24V
Body material:Aluminum Alloy
Diaphragm material:NBR (Common), FKM(Available)
Number of diaphragm:2
Action:Internal pilot operated
Pressure:0.1- 0.8MPa
Temperature:-25℃ to +80℃
Blowing area:27-38㎡

SBFEC Type Solenoid Pulse Jet Valve:

Model No.	D62
Replace For	DMF-Z-62S
Mounting Hole Dia.	8mm
Sealing Disc OD	90mm

Ref. Number	DMF-Y-62S
Working Pressure	0.1~0.8Mpa
Voltage	24V DC, 110V AC, 220V AC Other voltages can be customized.
Diaphragm Nos	2
Port Size	Φ75
Other requirement please contact.

Benefits of Dust Collecter System:
LOWER OPERATING COSTS
It reduces maintenance expenses, increase equipment life and lead to reduced energy costs by recirculating clean air within the workplace.

REDUCES RISKS
It improves safety and cleanliness in the workplace, thus reducing your health and fire risks.

INCREASED PRODUCTIVITY
It contributes to increased productivity by reducing equipment downtime, workers' sick days and on-the-job injuries.

IMPROVED PRODUCT QUALITY
It provides a nearly dust-free environment. This results in improved product quality and reduced product defects caused by dust contamination.

IMPROVED HEALTH AND SAFETY
It ensures a clean and healthy workplace possible.

WORKSAFE EPA COMPLIANCE
It assists you in meeting government regulations.

BETTER MORALE AND EMPLOYEE RETENTION
It leads to better employee morale and higher job satisfaction. This results in reduced hiring and training costs.



Construction:
Body and Dreeser Nuts: Aluminum (diecast)
Ferrule: 305 Stainless Steel
Armature: 430FR Stainless Steel
Diaphragm and Seals: Nitrile or FKM
Spring: 304 Stainless Steel
Screws: 302 or 304 Stainless steel
Diaphragm Seat: PA-66 (25 & 40MM standard), Nitrile-coated mild steel (76MM standard), Acetal (102MM standard) or FKM coated mild steel


Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing


Welcome to your any question and inquiry!
