SCG353A043 3/4'' Threaded Dust Collector Pulse Jet Solenoid Valve 24VDC 110VAC 220VAC

SCG353A043 ASCO Type Threaded Pulse Jet Valve

Type:SOLENOID VALVES
Brand Name:Brando
Model Number:SCG353A043
Application:General
Temperature of Media:Normal Temperature
Power:SOLENOID
Media:Air
Port Size:3/4'', 3/4''
Structure:Diaphragm
Voltage:AC24V, AC110V, AC220V, DC24V
Valve body material:Aluminum ADC12
Action Type:Diaphragm Pilot Operated
Function:2 Way, Normally Closed (NC)
Diaphragm Material:NBR, TPE
Temperature Range:-5 to +55℃
Pressure Range:0.3 to 0.8MPa
Integral Pilot Pulse Valves:SCG353A043, SCG353A044, SCG353A047, SCG353A050, SCG353A051
Remote Pilot Pulse Valves:G353A041, G353A042, G353A045

ASCO Type Solenoid Pulse Jet Valve:

Model No.	BB11036001
Ref No.	400325
Voltage	AC24V, AC110V, AC220V, DC12V, DC24V
Connection	DIN 43650A
Other can be customized, please contact us.

Model No.	BAPC211037301
Ref No.	C113444
NC/NO	NC
2 Way or 3 Way	2Way
Other can be customized, please contact us.

Model No.	A043
Ref No.	C113443
Replace For	SCG353A043
Mounting Hole Dia.	6.5mm
Sealing Disc OD	/

Ref. Number	SCG353A043
Working Pressure	0.3~0.8Mpa
Voltage	24V DC, 110V AC, 220V AC Other voltages can be customized.
Diaphragm Nos	1
Port Size	G3/4''
Other requirement please contact.

Benefits of Dust Collecter System:
LOWER OPERATING COSTS
It reduces maintenance expenses, increase equipment life and lead to reduced energy costs by recirculating clean air within the workplace.
REDUCES RISKS
It improves safety and cleanliness in the workplace, thus reducing your health and fire risks.
INCREASED PRODUCTIVITY
It contributes to increased productivity by reducing equipment downtime, workers' sick days and on-the-job injuries.
IMPROVED PRODUCT QUALITY
It provides a nearly dust-free environment. This results in improved product quality and reduced product defects caused by dust contamination.
IMPROVED HEALTH AND SAFETY
It ensures a clean and healthy workplace possible.
WORKSAFE EPA COMPLIANCE
It assists you in meeting government regulations.
BETTER MORALE AND EMPLOYEE RETENTION
It leads to better employee morale and higher job satisfaction. This results in reduced hiring and training costs.

Construction:
Body and Dreeser Nuts: Aluminum (diecast)
Ferrule: 305 Stainless Steel
Armature: 430FR Stainless Steel
Diaphragm and Seals: Nitrile or FKM
Spring: 304 Stainless Steel
Screws: 302 or 304 Stainless steel
Diaphragm Seat: PA-66 (25 & 40MM standard), Nitrile-coated mild steel (76MM standard), Acetal (102MM standard) or FKM coated mild steel
