cement silo
The sheet-assembled cement silo is designed for resolving the difficulties in export packing, on-site silo making, construction site transferring, extra-high and extra-wide transportation. The sheet-assembled cement silo is a kind of closed storage tank, which is safe, reliable, and convenient to be installed.
The sheet-assembled cement silo applies to engineering construction, concrete mixing stations, roads and bridges, water conservancy, urban construction and other projects. It is also suitable for storing grain, cement, fly ash and other bulk materials.
|
Type |
Volume |
Total Weight |
Tank diameter |
Tank height |
Total height |
Matched host |
Matched screw conveyor |
|
SNC 50
|
50T |
3T |
3m |
5.4m |
12m |
JS500 |
LSY185-6 |
|
SNC 100
|
100T |
5T |
3m |
12.4m |
18m |
JS1000 |
LSY200–9 |
|
SNC 150
|
150T |
7T |
3.2m |
13.4m |
18.6m |
JS1500 |
LSY250–9 |
|
SNC 200
|
200T |
9.6T |
3.6m |
13.6m |
18.6m |
JS2000 |
LSY300–9 |
|
SNC 300
|
300T |
14.3T |
4.5m |
12.6m |
18.6m |
JS3000 |
LSY300–9 |
Cement silo working principle:
1.Bulk cement truck transports the cement to the site.
2. Conveying the cement in truck to cement silo by the air pressure of the truck.
3. Conveying the cement in cement silo to the concrete mixer by the screw conveyor.
