solder ring copper fittings
5 year ago
45° Solder Ring Copper Elbow,Pre-solder Copper Elbow,Street Elbow
-
Description:90°Solder Ring Copper Elbow,90°Pre-solder Copper Elbow,Street Solder Ring Copper Elbow with UPC,NSF61,WRAS,SABS approval.
The solder ring elbow confirmed ASME B16.22 and EN1254-1 .We are the supplier of Mueller in U.S and have same type as Yorkshire in U.K .Our soder is produced according to SN99.3CU0.7.Moreover,the lead of solder is less than 0.01% which is much lower than the standard.And our solder ring inside the socket is as smooth as Yorkshire.No bubble hole on the surface.
The copper fittings known as copper pipe fittings,copper pressure fittings and copper plumbing fittings, divided to end feed copper fittings(wrot joint copper fittings ) and solder ring copper fittings(presolder copper fittings).And the quality of our EN1254-1 copper fittings can compare with yorkshire copper fittings(Pegler copper fittings) and connex copper fittings.our ASME B16.22 copper fittings also has exported to Mueller in U.S. Our 45° Copper Elbow Street Elbow and the 90° elbow are all used the change the water or gas direction.We also have end feed type for the choice.
-
Production Standard:
1.EN1254-1/BS864-2(Copper And Copper Alloys-Plumbing Fittings)
2.ANSI/ASME B16.22-2001(Wrought Copper And Copper Alloy Solder Joint Pressure Fittings)
-
Material:
Copper Part:
C12200(Cu-DHP CW024A ,SF-Cu 2.0090 and TP2)
Cu≥99.95% P0.015%-0.04% Impurity(P,Ag,Bi,Sb,As,Fe,Pb,Sn,S,Zn)≤0.1
Solder Part:
Sn99.3Cu0.7(Sn balance Cu0.5-0.9% Al≤0.001% Fe≤0.02% Zn≤0.001% Pb≤0.07% Ni≤0.01% Cd≤0.002% As≤0.03% Sb≤0.1% Bi≤0.1% Ag≤0.1% In≤0.1% Au≤0.05%)
-
Application: Industrial or Residential Water and plumbing,drinking supply,cold and hot water supply, heating supply, fire protection,gas supply, industrial petroleum pipeline system etc.
Suit Medium:Cold Water, Hot Water, Compressed Air, Gas, Oil Etc.
