Requirements for switching power supply transformers

The requirements for the transformer in the switching power supply are mainly that the leakage induction should be small, which can avoid transient saturation, and at the same time, the temperature effect should be considered and the structural design should be reasonable. The requirements of these aspects are expanded:

Reducing leakage is very important for switching transformers - voltage spikes caused by switching transformer leakage energy storage are one of the reasons for power switch tube damage. The size of the voltage peak when the power switching tube is turned off is related to the configuration of the collector circuit, the circuit turn-off condition and the size of the leakage induction, which requires the leakage induction of the switching transformer must be relatively small.

If the working magnetic flux density selection is large, the switching transformer will occur magnetic saturation at the moment of power-on. Because the switching transformer and the power switch tube are directly connected and have a high voltage, if the switching transformer is saturated, even if it is a short period of several cycles, it is easy to damage the power tube. Generally, soft start circuit is used in control circuit to avoid transient saturation.

The operating frequency of the switching power supply is generally relatively high, which requires that the power loss of the magnetic core material at the operating frequency should be as small as possible, and the reduction of the saturation magnetic flux density should be as small as possible with the increase of the operating temperature. Therefore, in the design and selection of magnetic core materials, in addition to caring about its saturated magnetic flux density, loss and other conventional parameters, but also pay attention to its temperature characteristics.
