1-1/4'' Anti Corrosion Resistance UPVC Solenoid Valve For Acid Alkali Chemical Corrosive Liquids 220V 110V 24V
5 month ago
This is an anti corrosive UPVC solenoid valve, 1-1/4'' female threaded port size, 32mm orifice size, 2 way normally closed, piston pilot operated, 0.1 to 6 bar working pressure, can be EPDM or FKM seal to suit different working mediums, various voltages for your choice, such as 12VDC, 24VDC, 24VAC, 110VAC and 220VAC, etc. It is used for a wide arrange of industrial applications to control fluids.
Product Features:
1. Working Medium: Chemical, Acid, Alkali, Corrosive Liquid, etc
2. Working Pressure: 0.1 to 6 bar
3. Port Size: 1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2''
4. Orifice Size: 15mm, 20mm, 25mm, 32mm, 40mm, 50mm
5. Body Material: UPVC
6. Seal Material: EPDM, FKM
7. Operation: Piston Pilot Operated
8. Function: 2 Way Normally Closed
9. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Technical Data:
|
Model No
|
Orifice Size
|
Port Size
|
Cv
|
Working Pressure
|
Body
|
Seal
|
Function
|
Voltage
|
|
FF1U15B04
|
15mm
|
1/2''
|
4
|
0.1 to 6 bar
|
UPVC
|
EPDM
FKM
|
2 Way NC
|
12VDC
24VDC
24VAC
110VAC
220VAC
|
|
FF1U20B06
|
20mm
|
3/4''
|
5.5
|
|||||
|
FF1U25B25
|
25mm
|
1''
|
13
|
|||||
|
FF1U32B32
|
32mm
|
1-1/4''
|
17
|
|||||
|
FF1U40B40
|
40mm
|
1-1/2''
|
25
|
|||||
|
FF1U50B50
|
50mm
|
2''
|
40
|
Main Dimension:
|
Model No
|
Port
|
A
|
B
|
C
|
D
|
E
|
F
|
|
FF1U15B04
|
1/2''
|
74
|
132
|
92
|
63.5
|
63.5
|
16
|
|
FF1U20B06
|
3/4''
|
80
|
137
|
92
|
63.5
|
63.5
|
19
|
|
FF1U25B25
|
1''
|
100
|
147
|
92
|
74
|
74
|
26
|
|
FF1U32B32
|
1-1/4''
|
120
|
171
|
94
|
94
|
94
|
30
|
|
FF1U40B40
|
1-1/2''
|
130
|
180
|
94
|
94
|
94
|
32.5
|
|
FF1U50B50
|
2''
|
172
|
225
|
94
|
155
|
155
|
42
|
