ZXS Seals (1)
3 year ago
Application range:
Working pressure:
≤16MPa (hydraulic)
≤1.6MPa (air pressure)
Operating temperature:
-35℃～+100℃ (hydraulic)
-35℃～+80℃ (air pressure)
Reciprocating speed:
≤0.5m/s (hydraulic)
≤1.0m/s (air pressure)
Type C1 Sealing Ring is especially suitable for plunger, piston rod, valve core, valve lift and low-speed pneumatic rotor (V≤0.2m/s, P<2.0MPa). When choosing a certain diameter seal, it should be as much as possible Choose a large section.
Install:
The outer diameter of the C1-type seal is larger than normal to ensure the required tight installation. Once installed, the sealing lip diameter will guarantee the ideal size. Type C1 seals fit easily into grooves.
Material:
The standard material is synthetic rubber based on nitrile rubber, Shore hardness: SHA 90° (hydraulic) SHA 80° (air pressure)
