Product details

Black White Blue Nylon6 PA6 Sheet

Black / White / Blue Polyamid Pa6 Sheets are conventional colors produced by AHD, while PA6 sheet is considered to be the most widely used well-known engineering plastic on the market. Nylon Sheet is often used as a general-grade material for mechanical parts


PA6 Sheet Main Properties:

1. High strength and stiffness

2. High impact and notch impact strength

3. High heat deflection temperature

4. Good at dampening

5. Good abrasion resistance

6. Low coefficient of friction

7. Good chemical stability against organic solvents and fuels

8. Excellent electrical properties, ease of printing and dyeing

9. Food safe, noise reduction


Application:

Nylon 6 Sheet Wear parts,transmission parts,home appliance parts,automotive parts,wire rod to prevent the machine parts,chemical machinery parts,chemical equipment.Such as turbine,gear,bearing,impeller,shaft,dashboard,drive shaft,valve,blades,wire rod,high pressure washers,nuts,seals,shuttle,bushing,etc

nylon sheet


White Nylon Sheet Specification:

Item name

PA6 sheet

Type:

extruded

Size:

1000×2000mm

Thickness:

8---100mm

Density:

1.15  g/cm³

Color:

White, black, blue

Brand name:

AHD

Material:

100% virgin material

Sample:

FREE


Nylon Plate Date sheet:


Item

PA6 SHEET

Color:

White,black, blue

Proportion:

1.15g/cm³

Heat resistance (continuous):

85℃

Heat resistance (short-term):

160℃

Melting point

220℃

Linear thermal expansion coefficient (average 23~100℃):

90×10-6 m/(m.k)

Average 23--150℃

105×10-6 m/(m.k)

Flammability(UI94):

HB

Tensile modulus of elasticity:

3250MPa

Dipping into water at 23℃ for 24h

86%

Dipping into water at 23℃

9%

Bending tensile stress/ Tensile stress off shock

76/- Mpa

Breaking tensile strain

˃50%

Compressive stress of normal strain-1%/2%:

24/46 MPa

Pendulum gap impact test

5.5 KJ/m2

Rockwell hardness:

M85

Dielectric strength:

25 kv/mm

Volume resistance:

10 14Ω×cm

Surface resistance:

10 13Ω

Relative dielectric constant-100HZ/1MHz:

3.9/3.3

Critical tracking index(CTI)

600

Bonding capacity:

+

Food contact:

+

Acid resistance:

-

Alkali resistance

+

Carbonated water resistance:

+/0

Aromatic compound resistance:

+/0

Ketone resistance:

+


Nylon 6 Sheet Goods Photos:

Virgin Blue Nylon 6 Sheet

PA6 polyamide 6 sheet

PA6 polyamide 6 sheet


Factory information:

Anheda Plastics Group is located in the Shenzhen Special Economic Zone, adjacent to Hong Kong, with convenient transportation by sea, land and air.Since its establishment, the company has put quality first, and adheres to the tenet of [Science and Technology, Cultivation of More Talents, Technology Development and Growth, and Innovation of Technical Talents". Our company is growing and developing step by step, and its economic strength is constantly improving, and its competitive advantage continues to stand out. We always abide by the business philosophy of "Quality First, Customer First", and customer satisfaction is our driving force.Mainly produce the PA6 Sheet , Abs Plastic Sheet or other products.
