SX9 SOLAR LIGHT TOWER
4 year ago
SV9 SERIES SOLAR LIGHT TOWET
Product display
Product data
|
SV9-P600/1525 |
||
|
Standard Model |
SV9-P600/ 1525 |
|
|
Dimensions |
Trailer Length |
3,890 mm (12' 9") |
|
Length for loading |
2,285 mm (7' 6") |
|
|
Width |
1,670 mm (5' 5½") |
|
|
Width while solar panels fully extended |
5,130 mm (16'10") |
|
|
Height/Hight for loading |
2,800 mm (9'2")/2,490 mm (8'2") |
|
|
Height fully extended |
8.30 m (27'3") |
|
|
Gross weight |
1,567 kg (3,439 lb) |
|
|
Solar panel & battery system |
System voltage |
24 VDC |
|
Solar panel system |
1,525 W- 5*305 W Mono |
|
|
Retractable panel system |
Manual sliding system with guide rail |
|
|
Panel sunshine tilt |
Manually 7.5°- 35° adjustable with 7,000 lb jack |
|
|
Battery |
750 Ah (6*250 Ah) gel or 300 Ah (2*150 Ah) lithium battery |
|
|
Controller (Day time) |
1*60 A MPPT controller |
|
|
Time of battery fully charged by solar |
3- 5 hours |
|
|
DC-AC inverter |
24 VDC-230 V or 120 VAC |
|
|
Power outlet |
A Receptacle 230 V or 120 VAC 15A |
|
|
Additional accessory |
A 30 ADC charger with cable & plug |
|
|
Mast & Luminaire |
Luminaire |
600 W-4*150 W LED (AC115-277 V) |
|
Luminous flux |
21,000 Lumen/ Light |
|
|
Auto LED turn on-off |
Controlled by dusk to dawn sensor |
|
|
Manual LED turn on-off |
Switch |
|
|
Mast style |
5 sections; 2,500 lb manual winch |
|
|
Mast rotation |
Manual 240 ° with self lock |
|
|
Light tilt |
Manual |
|
|
Trailer |
Suspension & brake |
Single leafspring axle without brake |
|
Tow bar |
"A" style frame with a directional wheel |
|
|
Forklift slots |
2 sides + rear |
|
|
Stabilizing leg |
4 retractable jacks |
|
|
Wheel |
16" rim with regular tire |
|
|
Tow Coupler |
2", 50 mm ball coupler or 3" pintle ring |
|
|
Taillights |
Night, turning & stopping taillights |
|
|
Max towing speed |
100 km/h (62 mph) |
|
|
General Data |
Max. lighting time for 4.5 average sunshine hours |
11- 12 hours |
|
Max. against wind |
20 m/s (45 mph, solar panels must be retracked) |
|
|
Max. load in 40' high cube |
7 | |
|
Standard System: 230 V or 120 VAC, with Dusk & Dawn and Manual ON/OFF Switch; Optional System: 24 VDC, with Timing and Manual ON/OFF Switch. |
||
|
R-Regular; P-Premium |
||
|
Designed by GRANDWATT Electric Corp. (U.S.A.) Made by GRANDWATT Electric Co., Ltd. (China) |
||
