UNR11 1-3KVA 220VAC Rack Online UPS

Model

UNRA1101KS

UNRA1101KL

UNRA1102KS

UNRA1102KL

UNRA1103KS

UNRA1103KL

Capacity

1kVA/1kW

2kVA/2kW

3kVA/3kW

Input

Nominal Voltage

208/ 220/230/240Vac, L+N+PE

Voltage Range

110~300Vac

Frequency Range

40-70Hz

Power Factor

≥0.99

THDi

≤4% (linear load); ≤5% (non-linear load)

Output

Nominal Voltage

208/220/230/240Vac ,L+N+PE

Voltage Regulation

±1%

Frequency

50/60Hz ± 0.1%

THDu

Hamonic Distrotion

 ≤2% (linear load); ≤5% (non-linear load)

Transfer Time

Zero

Waveform

Pure sine wave

Crest Factor

3:1

Overload Capacity

(Line Mode)

102%~110% load, 30min;110%~130% load, 10min;

130%~150% load, 30s; >150% load, 200ms

Overload Capacity

(Battery Mode)

102%~110% load, 1min;110%~130% load, 10s;

130%~150% load, 3s; >150% load, 200ms

Efficiency

Line Mode

94.5%

95.5%

95.5%

Battery Mode

88.5%

91.5%

91.5%

ECO Mode

98%

Battery

Battery Voltage

36Vdc

72Vdc

96Vdc

Battery Number

7Ah*3pcs

External

7Ah*6pcs

External

7Ah*8pcs

External

Charge Current

1A

1-12A

1A

1-12A

1A

1-12A

Communication

Interface

RS232 / USB/ SNMP card(optional) /Dry contact card(optional)

Environment

Operation

Temperature

0~40℃

Humidity

0~95%(non-condensing)

Noise

≤50dB@1meter away

Altitude

Up to 1000m without derating

Physical

Dimensions

(W*D*H)mm

440*379*86

440*379*86

440*568*86

440*450*86

440*719*86

440*450*86

Weight (kg)

10

4

18.5

6.4

25

8.2
