JBTS40-12-82R
2 year ago
Concrete Mixing Pump is a multi function machine which combines the function of concrete mixer and concrete pump. It can produce and deliver concrete.
Advantages of concrete mixing pump：
Perfect combination of mixing and pumping, saving the weight of the frame and transportation space;.
Small concrete transfer pump carrying mixer, easy to haul, high working efficiency;
Save labor cost and reduce labor intensity.
Smaller power, taking into account the carrying capacity of the power grid.
Simple operation, easy to use, with a remote control to operate the mixer pump.
Adopting double-cylinder full hydraulic pumping system, capable of conveying regular large aggregate or crushed stone concrete, stable performance, safe and reliable.
|
Items |
Units |
Parameters |
Parameters |
|
|
JBS40-10-45 |
JBS30-10-37 |
|||
|
Whole performance of machine |
Max. theo. concrete output |
m3/h |
40 |
30 |
|
Max. Theoretical stirring quantity |
m3/h |
15 |
15 |
|
|
Max.concrete pumping pressure |
MPa |
10 |
10 |
|
|
Distribution valve type |
|
S Valve |
S Valve |
|
|
Concrete cylinder diameter×stroke |
mm |
Ф180×1100 |
Ф140/845 |
|
|
Hopper capacity |
L |
700 |
700 |
|
|
Outlet diameter |
mm |
Ф150 |
Ф125 |
|
|
Power system
|
Winding motor power |
kw |
5.5 |
5.5 |
|
Stir the motor Power |
kw |
4.5 |
4.5 |
|
|
Water pump motor power |
kw |
0.55 |
0.55 |
|
|
Electrical engineering power |
kw |
45 |
37 |
|
|
Rotate speed |
r/min |
1480 |
1450 |
|
|
Hydraulic system |
Circuit type |
|
Open circuit |
Open circuit |
|
Pumping system pressure |
MPa |
28 |
28 |
|
|
Mixing system pressure |
MPa |
6-8 |
6-8 |
|
|
Capacity of oil tank |
L |
370 |
370 |
|
|
The biggest transportation is away from vertically (/Level) |
m |
90/300 |
120/300 |
|
|
Other parameters |
Max. aggregate diameter |
mm |
Scree: 40 |
Scree: 30 |
|
Inside diameter of delivering pipe |
mm |
Ф125 |
Ф80 |
|
|
Dimensions:length×width×height |
mm |
4500x2100x2800 |
4500x2100x2800 |
|
|
Total weight |
kg |
5000 |
4500 |
|
