Shell and Plate Heat Exchanger
Tower top step condensation to recover VOCs
Primary cooler
Media: PO + N2, R22
Hot side temperature: 15/5 ℃
Cold side temperature: -25 ℃ evaporation
Heat exchange power: 6KW design pressure: 25bar
Exhaust gas heater
Medium: R22, N2
Hot side temperature: 25/20 ℃
Cold side temperature: -70/5 ℃
Heat exchange power: 15KW
Design pressure: 25 bar
Secondary cooler
Medium: N2, R22
Hot side temperature: 5/-70 ℃
Cold side temperature: -75 ℃ evaporation
Heat exchange power: 40KW
Design pressure: 25 bar
Through multi-stage and compact plate and shell heat exchanger ( integrate the advantages of plate and frame heat exchanger & shell and tube heat exchanger), the propylene oxide in nitrogen is condensed down and recovered, and then the nitrogen is reheated and discharged.
