V8-Sport600/1200 PORTABLE LIGHT TOWER
*Solar light tower Zero emission, zero fuel consumption, dusk-dawn lighting.
The mobile LED light tower adopts telescopic mast, which is more safe and reliable. Reliable, fast deployable, easy and quick job site setup, and reduced downtime.
In addition, compact design, smaller volume during transportation, can save a lot of transportation costs!
We strive to provide you with the highest value added products.
Product description
Product Presentation
Product specifications
|
Sport series X8 Solar Light Tower |
||
|
Standard Model |
X8-Sport600/1200 |
|
|
Normal dimension |
Length |
2,030 mm (6'8") |
|
Width |
1,170 mm (3'10") |
|
|
Height |
2,820 mm (9'3") |
|
|
Dimension extended |
Length extended |
3,630 mm (11'11") |
|
Width extended |
2,670 mm (8'9") |
|
|
Height extended |
8,180 mm (26'10") |
|
|
Dimension for loading |
Length for loading |
1,880 mm (6'2" ) |
|
Width for loading |
1,170 mm (3'10") |
|
|
Height for loading |
2,495 mm (8'2") |
|
|
Gross weight |
812 kg (1,780 lb) |
|
|
Solar & electric system |
Solar & battery voltage |
48 VDC |
|
Solar system |
1,200 W - 3*400 W Mono |
|
|
Retractable panel system |
Manual sliding system with guide rail |
|
|
Panel sunshine tilt |
Manually 15°- 35° adjustable with 7,000 lb jack, 65° retracted completely for moving |
|
|
Controller (Day time) |
50 A MPPT controller |
|
|
Battery |
150 Ah Lithium battery |
|
|
Time of battery fully charged by solar |
3-5 hours |
|
|
DC-AC inverter |
48 VDC-230 or 120 VAC |
|
|
Power outlet |
A Receptacle 230 or 120 VAC 15A |
|
|
Additional accessory |
A 30 ADC charger with cable & plug |
|
|
Mast & Luminaire |
Luminaire |
600 W-4*150 W LED (AC115-277V) |
|
Luminous flux |
21,000 Lumen/Light |
|
|
Auto LED turn on-off |
Controlled by dusk to dawn sensor |
|
|
Manual LED turn on-off |
Switch |
|
|
Mast style |
5 Sections with manual winch |
|
|
Mast rotation |
Manual 210° with self-lock |
|
|
Light rotate & tilt |
Manual |
|
|
Cart |
Front wheels |
2 kits of double 400 mm wheels |
|
Rear wheels |
2 kits of rotable double 350 mm wheels |
|
|
Stabilizing leg |
6 retractable heavy duty jacks |
|
|
Forklift slots |
4 directions |
|
|
General Data |
Continuous lighting time if battery charged fully |
11 hours |
|
Max. against wind while solar panels retracked completely |
27.8 m/s (100 km/h) |
|
|
Max. against wind while solar panels extened completely |
14 m/s (50 km/h) |
|
|
Max. load in 40' high cube |
12 | |
|
Designed by GRANDWATT Electric Corp. (U.S.A.) Made by GRANDWATT Electric Co., Ltd. (China) |
||
